Product drawings

The features of Filn 6 pins rocker switch.

Filn 6 pins rocker switch has below features, such as waterproof and its waterproof rating is IP67, imported rubber, not easy to damage for long-time use. Its current can reach 20A 250V. The keys are painted, you can choose black or silver to make the appearance more beautiful.

The description of Filn 30A KCD2 on off waterproof 6 pins rocker switch.

1.The mounting hole size of Filn 30A KCD4 on off waterproof 6 pins rocker switch is 22*30mm, the panel thickness should be between 0.8 to 4mm, so the waterproof rocker switch can be stuck tightly, making the waterproof effect achieve better.

2.The Filn LED white 6 pins rocker switch can achieve a variety of voltages, such as 3V, 6V, 12V, 24V, 48V, 110V, 220V, 380V, etc. We can customize various different voltages by changing the resistance. Among which 12V, 24V, 220V are the common voltages.

3.The Filn 12AMP white 6 pins rocker switch can achieve five colors of red, yellow, blue, green, white, etc. The internal LED in non-polar, it irrespective of positive and negative poles.

4.As shown in the figure, the key of Filn KCD4 white 6 pins rocker switch is black painted, it can achieve the material of stainless steel, silver spray paint, transparent PC. It can made into yellow transparent cover and red transparent cover. We will use black solid cover if the product is without lamp.

5.The Filn on off 6 pins rocker switch mainly has the functions of on-off 4 pins and 2 gears, on-off-on 3 gears  and 6 pins, (on)-(off)-(on) double reset 3 gears and 6 pins, (on)-off single reset 4 pins and 2 gears, on-on 6 pins and 2 gears.

It all depend on your needs. The product in the picture is 6 pins rocker switch with the function of on-on 6 gears and 2 pins.

6.The connection mode is plug-in and its size is 6.3*0.8mm. In addition, we also have a direct-wired rocker switch, with black glue at the bottom, making the waterproof rating reach IP68. There is also a new developed product of which connection way is screw pin.

7.The Filn 30 AMP 6 pins rocker switch had passed the certifications of UL, CE, ROSH, etc. These international certifications proved that all the functions of Filn white rocker switch meet international standards, it can also be sold and used in the US and European markets.

8.The head of Filn 12V 6 pins rocker switch adopts nylon PC material, the lamp base and rocker switch base both adopts nylon PA66 material, it is flame-retardant and high-temperature-resistant. When the rocker switch is welded with wire pin, its base will not melt. The waterproof cap adopts silicone material, and the rocker switch’s metal pin adopts copper H62 material.

What is a 6 pins rocker switch ?

Filn on off 6 pins rocker switch means that install rocker switch on the panel and connect the wire, when your hand presses the button”O”, the rocker switch is energized. When release the rocker switch, it automatically reset and the rocker switch is cut off.

How to wire a KCD4 6 pins rocker switch ?

The wiring mode of KCD4 6 pins rocker switch is as follows.

1.Two switch pins are connected with the power supply, the other two lamp pins are connected with the device. Press the switch, the lamp will light then the device starts. Switch is closed, the light is dark and the device is closed.

2.Two lamp pins are connected with the power supply, the other two switch pins are connected with the device, keeping the switch light always on. Press the switch, device will start. Close the switch, device will be closed.

The advantages of Filn waterproof 6 pins rocker switch.

1.As a manufacturer and we have enough material stock, so the delivery period is very fast. Regular order will also be stocked in the warehouse, and the delivery period of 1000 convenient rocker switch can be completed within three days.

2.We can provide relevant certificates, specifications and other information quickly.

3.There is no MOQ, the panel section of the on off 6 pins rocker switch can customize the logo of your company’s content.

4.Filn has a professional team of engineers for R&D and design rocker switch, and a team of engineers specializing in the production of rocker switch mould. Filn can complete the new rocker switch design and mold development within 30 to 40 days.

5.Filn has premium warranty service and after-sales service.

Where does the 30A 6 pins rocker switch used?

Filn 30A 6 pins rocker switch is mostly used on home appliances and kitchen equipment, such as water dispenser, treadmill, computer speakers, battery car, motorcycle, ion TV, coffee pot, row plug, massage machine, etc.

How to purchase the waterproof 6 pins rocker switch?

You can buy our products directly through online at www.cnfiln.com, or you can buy the red 6 pins rocker switch through email communication offline. Single weight of the product is about 0.02kg. We will choose corresponding delivery way according to your purchase quantity. 1000 pieces are packed in one carton and its weight is 19kg. We can provide samples free of charge for your test.

The waterproof 6 pins rocker switch launched by Filn has the price competitiveness advantages in the same industry, it also has the most complete style. Filn has been widely praised at home and abroad for its product quality assurance. We will continue to develop a new 6 pins rocker switch to create a better image and brand power for the company. If you need our product, or you’re interested in our product, or you need the samples, etc, please contact us directly.Inquiry@cnylin.com.cn

Product Item	KCD4-0113-22
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

Product Drawings:

Product Parameters:

Product Item	KCD4-0113-23
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

How to wire a 3 position rocker switch?



6 feet 3 gears with light conventional wiring diagram，KCD4 three-stage six-pin waterproof rocker switch wiring mode: 1: two pins are connected to the power supply, the other two pins (lamp pins) are connected to the device, the switch is pressed, the switch light is on, the device is started, the switch is off, the switch light is dark, and the device is closure. 2: Connect the two light pins to the power supply and the other two pins to the device to keep the switch light on. Press the switch to start the device, turn off the switch, and the device shuts down.

FILN 3 position rocker switch Customization

What are the advantages of the 3 position rocker switch produced by FILN?

The 3 position rocker switch produced by FILN has the following advantages

1.The delivery time of FILN ROCKER SWITCH is very fast, and the delivery time of the conventional 3 position marine rocker switch 1000 will be about 2 days.

2.There is no minimum order for KCD4 ROCKER SWITCH, you can purchase 1 rocker switch or more.

3.The switching time of customized ship is very fast, such as 120v 3 position rocker switch or 3 position 6 pin rocker switch, usually orders can be shipped in the second day.

4.Complete international certification of ship type switch, UL CE ROSH ISO90001 quality management system certification, etc.

5.There is a professional R&D team for designing ship-type switches, which can provide overall solutions

6.The communication is barrier-free. FILN has 20 years of overseas sales experience and professional sales technical engineers, who can solve any problems about ship switches in the first time.

3 Where are position rocker switches used?

This 3 position marine rocker switch is generally used as a small high-capacity power switch for water dispensers, treadmills, computer audio, battery cars, motorcycles, massage machines, toy cars and other home appliances and office equipment, as well as kitchen equipment.

If you are using high-power products, you should choose 30A copper feet, such as: electric welding machine, heater, electric baking pan, electric oven, electric oven and other products, choose 30A copper feet.

Related products:

FILN 6Pin 30A on off on Waterproof 3 position rocker switch product introduction

l3 The installation size of the position rocker switch on off on is 22X30mm, you only need to open a 22x30mm hole on the rocker switch panel to insert it. The general thickness of the rocker switch panel is about 0.8 to 4mm, otherwise the waterproof rocker switch will The card is not tight, resulting in poor waterproof effect.

l3 There are 6 colors of position rocker switch on off on, among which red, green, yellow, blue and white can be used as a rocker switch with light. The black 30A rocker switch is without light.

30 rocker switch is waterproof, and the waterproof grade is IP65. You can use the waterproof rocker switch on medical equipment or kitchen equipment.

The maximum current of the 3 position 6 pin rocker switch can be produced to 30A 250v. You can directly install the 3 position 6 pin rocker switch on mechanical equipment with a power below 5000W.

The voltage of 3 position 6 pin rocker switch can be made into 3V, 6V, 12V, 24V, 110V, 120V, 220V, 250V, 380V, etc. In Europe, 110V, 120V 30A rocker swtich are usually used, and in China, 220V, 250V are usually used. UL rocker switch.

3 The biggest advantage of position rocker switch?

Regarding this 3 position rocker switch, the biggest advantage is that it can be made into a large current 30A, one-piece waterproof cover made of silicone waterproof material. Copper feet, high temperature resistant shell. There are CE, ROHS and other certifications.

You can also customize your company’s trademark symbol and print it on the shell, and the O/I logo can also customize the symbol you want.

The 250v 30A rocker switch has UL, CE, ROSH and other certifications to ensure that the quality of the rocker switch meets international standards. It can also be sold and used in the United States and the European Union.

l3 position 6 pin rocker switch is dual-channel, the function is ON OFF ON function, it can also produce automatic reset ON OFF (ON), (ON) OFF (ON) function.

lThe plastic base of the 12v 30A rocker switch is made of nylon double material, and the temperature resistance can reach 260 degrees, which ensures that the contact of the rocker switch will not melt when the contact of the rocker switch touches the heating plastic when the current is high, which ensures the safety of the product.

lThe button shell can be black-plated, silver-plated, stainless steel, etc.

How to buy this 3 position rocker switch?

If you are interested in 3 position rocker switch, you can send us an email according to your requirements, such as product pictures, lamp color, voltage, current, etc., or you can place an order directly at www.cnfiln.com and note your needs, We will contact you and confirm with you within 24 hours, and then send it to you after confirmation.

If you have a courier account, our company can also send you free samples.

Rocker switch drawings/Parameters:

Product Parameters:

Product Item	KCD4-0113-21
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

How to wire a 12V rocker switch?

The wiring way of the 4 pins waterproof 12V rocker switch is that the two side pins are connected with the power’s positive and negative poles, the lamp pins are connected with the device.

When pressing the 12V rocker switch, the key brights up and the device starts up. Press the switch again, the LED is off and the device is off. The switch is not always bright in this connection way.

 Foot button switch video

Customized 12V Rocker Switch：

The end of the 12V Rocker Switch is fully sealed, which can effectively play a waterproof effect, and can be used normally for a long time in a wet environment.

FILN provides customized production service, from voltage to appearance to meet your needs.

Applications:

• Industrial Applications
• Home Automation
• Automotive Integration
• Medical Devices
• Consumer Electronics
• Public Infrastructure
• Commercial Use
• Security Systems
• Hospitality Industry
• Transportation Use

Related products:

The features of the 12V rocker switch:

1. The cover surface is painted to achieve a variety of symbols and patterns, and the patterns will light up.
2. The previous rocker switch was not waterproof, while this 4 pins rocker switch is waterproof and its rating is IP67.

The description of the 4 pins white 30 AMP on off waterproof light 12V rocker switch.

1. The mounting hole size of the 4 pins 12V rocker switch is 22*30, you just need to open the hole of 22*30 on the rocker switch panel, then clutch the 12V waterproof rocker switch on the panel, it can be fixed and waterproof.
2. The transparent upper cover of the 12V rocker switch adopts PC high-temperature resistant material（①）, which can guarantee the LED rocker switch’s lighting effect. The transparent sheet has a spray painting process on it, and a variety of symbols and patterns can be customized. When the 12V rocker switch is powered up, the rocker switch light and pattern both light up, which is very beautiful.
3. The silicone gel sleeve adopts silicone material（②）, it is oil-resistant and waterproof. Clutch the waterproof cap between the top cover and the lamp seat of the rocker switch, so it has the function of waterproof.
4. The lamp of the 12V rocker switch light is LED（③）, it can achieve a variety of colors, such as red, yellow, green, blue, white, etc. Among them, the red rocker switch is the most popular in China.
5. The voltage of the 4pins 12 V rocker switch can be changed by changing the size of the resistance value, so the product can achieve a variety of voltages, such as 3V, 12V, 24V, 110V, 120V, 220V, etc. 120V rocker switch is the most popular in America.
6. The current of the white 12V rocker switch is 30AMP, the middle and side pins of the draw bored both adopt purple copper material（⑩）, the silver point is 4MM40 silk. If the machinery equipment’s power is below 4000W, you can use the 30 AMP rocker switch directly.
7. The base of the 12V on off rocker switch is yellow and adopts nylon double material, its temperature resistance can reach 260 degrees, so ensure the use of high current and high-power products.

Type of ship type 12v rocker switch:

12V rocker switch is often used as the power switch of electronic equipment. Its contacts are divided into SPDT and DPDT.

Single pole single throw: 1 dynamic contact and 1 static contact. There is only one channel. This type of switch is relatively simple. It used to be used a lot, but now it’s basically not used.

SPDT: one moving contact and two static contacts (static contacts on both sides can be connected respectively), but there are two static contacts, which can be connected with static contacts on both sides respectively.

Double pole single throw： two dynamic contacts and two static contacts, with two channels. Double pole single throw 12V rocker switch has two dynamic contacts and two static contacts respectively, which is one more channel than single pole single throw switch.

DPDT：2 moving contacts and 4 static contacts, 4 channels (2 static contacts on both sides can be connected respectively)
Our model is double pole single throw or double pole double throw

The common problems of the 12V rocker switch

1. The ear buckle of the rocker switch often breaks off.

The reason why the ear buckle of the rocker switch is easy to break is that many people adopt old plastic to produce rocker switch’s base.

If you want to solve this problem, please use the latest quality plastic to produce it.



2. The rocker switch is often burned out or the plastic is melted away.

There are two reasons for design and material, whether the rocker switch’s pin is purple copper or silver point.

When the current is large, it will be greater in instant contact, then the spark will generate heat.

Metal materials can heat up and cause the plastic to melt away if the material is of low quality.

What is a 12V rocker switch?

The 12V rocker switch means that the product is installed on the panel, then connect to the device.

If the product is 12V light rocker switch, turn on the 12V voltage, the light will bright up and the machine will also start. The switch will burn out if the voltage is much large than 12V.

Where are the 4 pins 12V rocker switch used?

The 12V rocker switch is used for water dispensers, treadmills, computer speakers, battery cars, motorcycles, ion TVs, coffee machines, power boards, massage machines, etc. It is mainly used for household appliances.

The power switch of the electrical appliances used in our lives is basically a 12v rocker switch.

Because the application range of the 12v rocker switch is so wide, these are mainly determined by its characteristics, mainly because it does bring great convenience to our daily life, and it is extremely simple to use and has a relatively high safety factor. This is a very important reason.

The advantages of the 12V rocker switch of Filn?

1. There is no MOQ, you can purchase the 12V waterproof product from one piece.
2. The 30A rocker switch had passed the certifications of UL, CE, ROSH, it can be sold in the US area.
3. The product can achieve a variety of voltages, such as 125V rocker switch, 110V rocker switch, 12V rocker switch, etc.
4. Filn has 15 years of overseas sales experience about rocker switches and is familiar with foreign trade processes in various countries.
5. Filn has a professional production team, with an automated rocker switch production line, the 10,000 pieces of products will be completed within 7 days.
6. They can provide a complete solution for a rocker switch.
7. The warranty period of the 4 pins 12V 30A waterproof is 5 years, Filn will change the problem product free of charge during the guarantee period.

How can i buy the 12V rocker switch?

50 pieces of the 4 pins 12V rocker switch are paced in one box, 1000 pieces are packed in one carton. The weight of 50 pieces is 1.5KG. If you need a small amount of this product, you can place an order at www.cnfiln.com directly.

If you want to custom the rocker switch, you can list your requirements, such as the color and voltage of the 110V rocker switch. Our email address is inquiry@cnylin.com.cn.

Filn has 20 years of experience in rocker light switch producing and also has a professional R&D team.

They can customize the rocker switch scheme for you within 24 hours. Filn also has over 10 years of overseas sales experience, so they can communicate and solve international trade problems.

If you have any questions regarding the rocker switch, please contact us, our email address is inquiry@cnylin.com.cn.

Our online shop

What are the features of white rocker switch 12V?

The waterproof rating of the white rocker switch 12V is IP67, it adopts import rubber material, which can ensure the quality. It not only has the function of waterproof, but also has a long service life. Besides, its current can reach 20A/ 250V. The keys are painted, it can be sprayed black or silver paint, making the appearance more beautiful.

Product Item	KCD4-0124-22
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

The description of the 6 pins KCD4 12V 15 AMP LED white rocker switch.

1.The mounting hole size of the 6 pins KCD4 12V 15 AMP LED white rocker switch is 22*30mm, the thick of the rocker switch panel need to between 0.8-4mm, so the waterproof rocker switch can be tightened with the panel, making the waterproof effect achieve better.

2.The LED white rocker switch can achieve a variety of voltages, such as 3V, 6V, 12V, 24V, 48V, 110V, 220V, 380V, etc. We can customize a variety of different voltages by changing the resistance, among which 12V, 24V, 220V rocker switch is the best-selling.

3.The 12V white rocker switch can achieve five colors of red, yellow, blue, green, white, etc. The internal LED is polar LED regardless of positive or negative. We can also produce the 12V white rocker switch without lamp.

The market demand of the white rocker switch is relatively large.

4.As shown in the picture, the key of the KCD4 white rocker switch is silver painted, it can be made into stainless steel material, black spray paint material, transparent PC material, such as yellow transparent cover, red transparent cover. If the product is without lamp, the cover is black solid cover.

1.The 4 pins white rocker switch has the functions as below

ON-OFF four pins and two gears

ON-OFF-ON three pins and six gears

ON-OFF-ON  double reset three pins and six gears

ON-OFF single reset four pins and two gears

ON-ON six pins and two gears

rocker switch ON-OFF two gears and six pins

The connecting way of the LED white rocker switch is plug-in and its size is 6.3mm. Besides, we also have a rocker switch with wiring, the bottom is with black glue, and the waterproof rating reaches IP68. We also research and development a new product, which connection way is screw pin.

What is the white rocker switch ?

KCD 4 white rocker switch means that install the rocker switch on the panel, then connect the wire. When your hand press the tab of “O”, the rocker switch is energized. When release your hand, it automatic reset, and the rocker switch is off.

How to wire the LED white rocker switch ?

The wiring ways of the KCD4 white rocker switch 12V are as follows

The waterproof white rocker switch has two wiring ways, the first way is that the two side pins of the rocker waterproof switch are connected to the positive and negative pole of the power, the switch’s two light pins are connected to the device. When press the switch, the light guide key is on and the device starts. Press the switch again, the light guide key is off and the device is closed. In this wiring mode, the light guide key is not always on, it is generally used in a light-normal environment.

The second wiring way is that the two lamp pins of the switch are connected to the positive and negative pole of the power, the switch’s two side pins are connected to the device. This moment, the switch light guide key is usually bright, press the switch, the device starts. When the switch is closed, the device is closed, and the light guide key remains bright. The light guide key is always on, it is generally used in a environment

with dark light.

The advantages of the white rocker switch produced by Filn？

1.We are a manufacturer and have sufficient material, so the delivery period is short. We have well-stocked of the conventional product, we can complete the 1000 pieces conventional rocker switch within 3 days.

2.We have completed certifications and specifications and can provide them quickly.

3.There is no MOQ, the panel of the 12V rocker switch can be customized LOGO and other content.

4.We have a professional R&D team and can provide the custom service.

How to purchase the white rocker switch?

You can purchase our product online at www.cnfiln.com, or via offline email communication. Per weight of the product is about 0.02 kg, we will choose the delivery way according to customer’s purchase quantity. One carton is packed in 1000 pieces, and the weight of one carton is 19 KG. We can supply samples free of charge for your test.

Filn has 20 years of experience in rocker light switch producing, and also has a professional rocker switch R&D team. They can customize a rocker switch scheme for you within 24 hours. Filn also has 10 years of overseas sales experience and can solve the international trade problems timely. If you have any questions about the rocker switch, please contact us immediately, our email address is inquiry@cnylin.com.cn.

Product drawings

What is a 30AMP 12V on off LED rocker switch?

The LED rocker switch is suitable for water dispenser, treadmill, computer speaker, battery car, motorcycle, ion TV, coffee machine, power board, massage machine, etc.

The power switches used for our household appliances are basically LED rocker switch.

1.The mounting size of the 12V LED rocker switch is 30*22mm, the installation mode is a buckle. You just need to open a mounting hole of 30*22mm, and then put the LED rocker switch into the mounting hole, the ears on both sides of the LED rocker switch will jam the panel. It is very convenient to use, the panel thickness should be between 0.8 to 2mm.

2.The waterproof rating of the LED rocker switch is IP67, through a waterproof cap inform the seal, and the waterproof cap adopts silicone material, it is waterproof and oil prevention and can be used on the machine equipment.

3.The current of the LED rocker switch is 30A, we can also provide the product with the current of 15A and 20A.

4.The voltage range of the LED rocker switch is 3 to 220V, the common voltages are 3V, 6V, 12V, 24V, 110V, 120V, 220V, 250V.

5.The LED rocker switch can achieve five colors of red, green, yellow, blue, white.

1.The service life of the LED rocker switch is 100,000 times with the power of 1,000W. If the power is higher than 1,000W, the service life will become shorter, while the power is below 500W, the service life will become longer.

2.The LED rocker switch of Filn had passed the certifications of UL, CE, ROSH, etc. These international certifications demonstrate that the product’s functions meet the international standards. It also ensure the quality of the 30AMP 12V on off LED rocker switch, it can be sold and used in the US and European markets.

The key of the LED rocker switch adopts 304 stainless steel, it is mill-resistant and corrosion resistant. The lamp base and the switch’s base adopt nylon PA66 material, it is flame-retardant and high-temperature resistant. When the rocker switch is welded with a wire lamp pin, it won’t cause the rocker’s base to melt. The waterproof cap adopts silicone material and the metal pin of the rocker switch adopts copper H62 material.

3.The LED rocker switch has three functions of on off, on on and reset on off.

How to connect the rocker switch with LED?

Firstly, connect the two side pins with the positive and negative poles of power, then two light pins are connected with the device. When press the LED rocker switch, the switch key light up and the device starts. Press the switch again, the rocker switch’s LED is off and the device is closed. The switch does not often bright with the wiring mode.

How to buy a LED rocker switch ?

You can purchase our product directly from the online store of Alibaba, or you can buy the LED rocker switch through offline email communication. There is no MOQ requirement. 50 pieces of rocker switch are packed in one box, and 1000 pieces are packed in one carton, the weighty of 50 pieces product is 1.5kg.

The advantages of the 30AMP 12V on off LED rocker switch.

1.There is no MOQ for the LED rocker switch of Filn, we can provide the samples free of charge for your test.

2.Filn can provide customized service, and weld the wire directly on the rocker switch. Follow-up directly wiring.

3.The LED rocker switch of Filn had passed the certifications of UL, CE, ROSH, etc, ensuring the product’s quality and consistency.

4.Filn has a professional team of engineers to design rocker switch, and also has a team of engineers specializing in producing rocker switch moulds. They can basically complete new product’s design and mould development within 30 to 40 days.

5.Filn’s sales staff are all sales engineers who can solve and respond to any customer questions about the rocker switch at the fastest possible time.

If you need our product, or you are interested in our products, or you want to the samples, please contact us directly. Our email address is inquiry@cnylin.com.cn.

Product Item	KCD4-0124-21
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

Product drawings

The features of the lighted rocker switch

The lighted rocker switch has an exclusive patented design, the surface of stainless steel cover adopts the design of friction-proof, explosion-proof and rust-proof, making the service life more longer and secure. The waterproof rating can up to IP67 benefit by the unique waterproof frame design. Besides, the rated power of the switch up to 30A 250V benefit by the purple copper thick silver layer.

The description of the 4 pins SPST RV 12V waterproof blue lighted rocker switch.

1.The 4 pins SPST rocker switch has 4 pin. The function of the switch is SPDT ON OFF. In addition, we also produce the product with the function of ON ON 6 pins DPDT, ON OFF ON 6pins DPDT, and reset function OFF-(ON), (ON)-OFF-(ON) dual reset function.

2.The waterproof lighted rocker switch’s cover is stainless steel, it is anti-friction, explosion-proof, anti-rust design, making the switch’s service life more longer and secure. In addition to the stainless steel, we can also make ordinary transparent cover, black solid cover, spray white paint with light cover, spray black paint with light cover.

3.If you want the blue light rocker switch spray white paint with lamp cover, or spray black paint with lamp cover, we can customize the lamp’s symbol shape.

4.There is no MOQ of the 12V lighted rocker switch, factory direct selling and has no intermediate cost, we also accept customized services such as welding wires and connecting terminals.

5.The 4 pins 12 volt white 30AMP marine rocker switch is suitable or the marine rocker switch panel, which size is between 0.8 and 4mm. You just need to open a hole of 30*22 on the switch panel and clutch the switch smoothly.

6.The waterproof leather cover of 30AMP rocker switch is with frame type, making the rocker switch rubber and rocker switch fit closer. The silicone material is oil-proof and waterproof, so that the switch reaches the IP67 waterproof rating. These type of switches can be used in kitchen equipment, yachts, cars, outdoor tools, etc.

7.The waterproof lighted rocker switch can achieve five colors of red, green, blue, yellow, white. It can achieve a variety of voltages, such as 3V, 6V, 12V. 24V. 36V, 110V, 220V, 380V, we also accept customization.

8.The plastic base of the 12 volt rocker switch is nylon double material, its temperature resistance can reach 260 degrees, ensuring that the rocker switch does not melt when contact point is in contact with the heating plastic at high current. It is suitable for high temperature equipment such as water heater, electric blast furnace, chocolate machine, hair dryer, etc.

9.The service life of the 4 pins lighted rocker switch is 100,000 times. If it is higher than 5000 W, the service life will become shorter, while it is below 1000W, the service life will become longer.

How to hook up a lighted rocker switch?

The 2 middle pins of the 4 pins lighted rocker switch is lamp pins, if you want to keep the rocker switch light on alone, you connect 2 middle pins to the power. The other 2 pins are connect with the device. This can realize the function of rocker switch light normally bright, and switch control equipment

How to buy the RV lighted rocker switch?

1.We have our own official website www.cnfiln.com ,you can search for the specifications you need and email us your requirement, we will reply to you at once.

2.We also have online sales platform, such as Aliexpress, Alibaba, Amazon, you can search Filn and place orders directly. If you have any questions, please contact our customer service staff on the relevant platforms, they will respond to your questions in time.

The advantages of the 4 pins lighted rocker switch produced by Filn.

1.The waterproof rating of the waterproof rocker switch can up to IP67.

2.The high rating rocker switch can withstand the high power of 30A and high current.

3.The rocker switch of Filn had passed the certifications of UL, CE, it can be sold in the European and American markets.

4.The marine rocker switch’ price is reasonable and practical.

5.We service 24-hour team service, and can reply your questions about technology, transportation, delivery date.

6.We provide factory outlet price, there is intermediate cost.

7.We usually prepare inventory and material for the conventional 12V rocker Switch，220V rocker switch , 110V rocker switch, we can meet customer’s emergency demand.

8.We have four technical engineers with 20 years of experience in research and development, providing professional solutions and design suggestions for customers to to develop and customized products.

9.Our company has heavy laboratory, UL certified experimental equipment, life test bench, temperature resistance test machine, aging test machine, microscope tester, tensile tester, pressure resistance test table, etc., professional equipment time sampling to detect the quality of our products, ensuring the safety and stability of each batch products.

10.We have stable staff, and provide staff training regarding the process, and equipment operation safety training.

11.Our rocker switch is semi-automated production, which greatly accelerates the progress of pure manual production, accelerates the delivery period, and can meet the customer’s demand of urgent orders in the first time.

12.Our rocker switch workshop is also equipped with cable cutter, terminal machine, and other customized service equipment, to achieve one-stop service needs for end customers.

13.Filn has 20 years of experience in rocker light switch producing, we also have a professional rocker switch R&D team, they can provide the solutions about the rocker switch within 24 hours. Filn also has over 10 years of overseas sales experience, they can communicate and solve international trade problems timely. If you have any questions about the rocker switch, please contact us immediately, our email address is inquiry@cnylin.com.cn.

Product Item	KCD4-0114-21
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

Momentary  on off on Rocker Switch’s features

Regarding this momentary on off on rocker switch, the biggest advantage is that it can make a large current 30A, one-piece waterproof cover made of silicone waterproof material. Copper feet, high temperature resistant shell. There are CE, ROHS, and other certifications.

You can also customize your trademark symbol, which can be printed on the shell, and the II/O/I logo can also be customized to the symbol you want.

The 250v 30A rocker switch has UL, CE, ROSH and other certifications to ensure that the quality of the rocker switch meets international standards. It can also be sold and used in the United States and the European Union.

FILN Third Gear Momentary on off on Rocker Switch product introduction

The installation size of Third Gear Momentary on off on Rocker Switch is 22X30mm, you only need to open a 22x30mm hole on the rocker switch panel to get it in. The general thickness of the rocker switch panel is about 0.8 to 4mm, otherwise the waterproof rocker switch It will not be stuck tightly, resulting in poor waterproof effect.

Third Gear Momentary on off on Rocker Switch has 6 colors, among which red, green, yellow, blue, and white can be used as a lighted rocker switch. The black 30A rocker switch is without light.

Third Gear Momentary on off on Rocker Switch is waterproof, and the waterproof level is IP65. You can use the waterproof rocker switch on medical equipment or kitchen equipment.

The maximum current of Third Gear Momentary on off on Rocker Switch can be produced to 30A 250v. You can directly install Third Gear Momentary on off on Rocker Switch on mechanical equipment with power below 5000W.

On off on momentary rocker switch wiring, the voltage can produce 3V, 6V, 12V, 24V, 110V, 120V, 220V, 250V, 380V, etc. In Europe, 110V, 120V 30A rocker swtich are usually used, and in China, 220V, 250V are usually used. UL rocker switch.

on off on momentary rocker switch wiring is two-way, the function is ON OFF ON, it can also produce resetting ON OFF (ON), (ON) OFF (ON) functions.

The plastic base of the 12v 30A rocker switch is made of nylon double material, and the temperature resistance can reach 260 degrees, which ensures that the contacts of the rocker switch will not melt when the contacts contact the heating plastic when the current is high.

The button shell can be black-plated, silver-plated, stainless steel, etc.

How to on off on momentary rocker switch wiring?

6 feet 3 gears with light on off on momentary rocker switch conventional wiring diagram

KCD4 three-stage six-pin waterproof rocker switch wiring mode: 1: Two pins are connected to the power supply, the other two pins (lamp pins) are connected to the device, the switch is pressed, the switch light is on, the device starts, the switch is off, the switch light is dark, and the device is closure. 2: Connect the two light pins to the power supply and the other two pins to the device to keep the switch light on. Press the switch to start the device, turn off the switch, and the device shuts down.

What are the advantages of the momentary on off on rocker switch produced by FILN?

1.Momentary on off on rocker switch production and delivery are very fast, and the delivery time of 1000 regular momentary on off on rocker switches will be about 2 days.

2.Momentary on off on rocker switch is not ordered, you can purchase 1 rocker switch or more.

3.The switching time of customized ship is very fast, such as momentary on off on rocker switch, usually can be shipped on the second day of the order.

4.The ship type switch international certification certificate is complete, with UL CE ROSH ISO9001 and other quality management system certifications

5.There is a professional R&D team for designing ship-type switches, which can provide overall solutions

6.The communication is barrier-free. FILN has 20 years of overseas sales experience and professional sales technical engineers, who can solve any problems about ship switches in the first time.

Where are momentary on off on rocker switch used?

This momentary on off on rocker switch is generally a small high-capacity power switch used in water dispensers, treadmills, computer audio, battery cars, motorcycles, massage machines, toy cars and other home appliances and office equipment. It can also be used in kitchen equipment. Wait.

If you are using a high-power product, you should choose a copper foot 30A, such as: electric welding machine, heater, electric baking pan, electric oven, electric oven, etc.

How to buy this momentary on off on rocker switch?

If you are interested in momentary on off on rocker switch, you can send us an email according to your requirements, such as product pictures, lamp color, voltage, current, etc., or you can place an order directly on www.cnfiln.com Remark your needs, we will contact you within 24 hours and confirm with you, and then send it to you after confirmation.

If you have a courier account, our company can also send you free samples

Product Item	KCD4-0312-23
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	20A, 30A

Product drawings

The biggest advantages of the 30A rocker switch.

The biggest advantages of the 30A rocker switch is that the product can achieve large current of 30A. It is made into an integrated type which material is silicone and waterproof.

The description of the 4 pin 250V 12V UL illuminated 30A rocker switch



The mounting hole size of the illuminated 30A rocker switch is 22*30mm, you can open a hole of 22*30mm on the panel, then let the 30 AMP rocker switch clutch in. Please refer to the drawing of 30A rocker switch.

The 12V 30A rocker switch has six colors, among which, red, green, yellow, blue, white, can be used to produce lighted rocker switch. The black 30A rocker switch is without lamp.

The waterproof rating of the 30A rocker switch is IP65, it can be used on medical equipment or kitchen equipment.

The maximum current of the 30A rocker switch can reach 30A 250V, you can install the 4 pins 30A rocker switch on the mechanical device with power below 5000W

The UL 30A rocker switch can achieve a variety of voltages, such as 3V, 6V, 12V, 24V, 110V, 120V, 220V, 250V, 380V,etc. 110V and 120V 30A rocker switch are popular in America, while 220V and 250V UL rocker switch are popular in China.

The KCD4 4 pins rocker switch is double circuits, and has the function of ON OFF, it also has the function of self-reset ON OFF rocker switch.

The plastic base of the 12V 30A rocker switch adopts nylon double material, which temperature resistant is 260 degrees, ensuring the rocker switch won’t melt when contact point is in contact with the heating plastic.

The 250V 30A rocker switch had passed the certifications of UL, CE, ROSH, etc. These ensure that the rocker switch’s quality meet the international standard, it can be sold and used in the United States and the EU.

The service life of the illuminated 30A rocker switch is 100,000 times. The switch’s warranty period is 5 years, Filn will replace the problem product free of charge if there is any quality problems during the warranty period.

What is the 12V 30A rocker switch?

The 12V 30A rocker switch has the function of ON OFF, its lamp voltage is 12V, and the current is 30A, the waterproof rating is IP65.

How to wire a illuminated 30a rocker switch ?

Regarding the illuminated 30A rocker switch, the wiring diagram of 4 pins 2 gears lighted rocker switch is as follows.

Where does the 30A rocker switch used?

 The 30A rocker switch is generally used in the drinking dispenser, treadmill, computer audio, battery car, motorcycle, massage machine, toy car and other home appliances, office equipment, and kitchen equipment, etc.

If you use a high power product, you need to choose the 30A rocker switch with purple copper pin. Such as  electric welder, heating apparatus, Electric cake pan, electric baking oven, electric oven.

How to purchase the 250V 30A rocker switch?

 If you are interested in the 250V 30A rocker switch, you can list the information of product picture, light color, voltage, current, etc and email us. You can place orders directly at www.cnfiln.com and list your needs. We will contact you within 24 hours.

If you have courier account, we provide samples free of charge for you.

The advantages of the 30A rocker switch produced by Filn?

1.There is no MOQ, you can purchase from one piece. We can provide many styles and colors rocker switch.

2.There are many types of rocker switch.

3.The delivery speed of the 30A rocker switch is fast, it can be completed within one days.

4．Rocker Switch can be customized

Filn has 20 years of experience in rocker switch producing, and also has a professional rocker switch R&D team. They can customize the rocker switch scheme for you within 24 hours. Filn has over 10 years of overseas sales experience. They can communicate and solve the international trade problem. If you have any questions about the rocker switch, please contact us, our email address is inquiry@cnylin.com.cn.

Product Item	KCD4-0312-21
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	20A, 30A

Product drawings

The features of the momentary autozone rocker switch.

The momentary autozone rocker switch is a self-reset autozone rocker switch. Meanwhile, its waterproof cover is made with a hard plastic frame, clutched on the panel hole, the waterproof effect is better. The overall appearance looks more three-dimensional. Interior use a large contact, and the maximum current can up to 30A 250VAC.

The description of the Filn 4 pins 30A 12V momentary autozone rocker switch.

1.The open hole size of the product’s panel is 30*28mm, its structure is 2 gears of off-on and the connect pin’s size is 6.3*0.8mm. Its material is nickel-plated, having better corrosion resistance and oxidation resistance.

2.The cover of the autozone rocker switch adopts PC material. Its high light transmittance makes the lamp light up more beautiful, and his temperature resistance makes the product durable. The cover has the colors of red, green, yellow, blue, white, black. The common printing of the cover is “I O”，it means (ON)-OFF, we can also print other symbols according to your requirement.

3.The autozone rocker switch is lighted or without lamp. The LED lamp can achieve the colors of red, green, yellow, blue, white, meanwhile it has a variety of voltages, such as 3V, 5V, 6V, 12V, 24V, 48V, 110V, 220V, 250V. We can provide 380V of three-phase electricity.

4.The current of the autozone rocker switch is 30A 250VAC, the diameter of the interior contact is 4.0mm, and the thickness is 0.2mm, its material is silver contact, the drawboard and connect pin both adopt copper plated nickel.



5.The base of the autozone rocker switch adopts PA66 strengthen nylon, its maximum temperature resistance can reach 260 degrees, and it is more secure in use since it is a flame-retardant material.

6.The autozone rocker switch is clutched on the hole of 30*22mm, and the panel’s thickness should be between 2 to 5mm, the installation is simple and fast.

The advantages of Filn 4 pins autozone rocker switch.

The material of the 4 pins autozone rocker switch adopts brand new nylon PA66 material, its shell color is yellow, this can make the product has a longer service life. In a low temperature environment, the shell is not easy to crack, meanwhile it is high-temperature resistant and fireproof. The interior is a 4.0mm large silver point, which is not easy to produce sparks after a long time use, and is more safe. We can provide different voltages and colors product to meet customer’s requirements.

How to wire a 30A autozone rocker switch?

The following is a brief wiring diagram of the 30A autozone rocker switch. When press down the rocker switch’s key, the lamp will light up, device starts to work. When release your hand, device is power off and the light is off.

How to buy a 12V autozone rocker switch?

50 pieces of products are packed in one box, 1000 pieces are packed in one carton, the weight of 50 pieces of products is 2kg. If you need a small amount of autozone rocker switch, you can place an order at www.cnfiln.com, we have inventory and can arrange the delivery as soon as receiving your order.

If you want to customize product or need the surrounding supporting wiring harness, you can list your requirements, such as connecting the wiring in advance, or install the custom quick connection terminals, or special voltages. Then email us, our email address is inquiry@cnylin.com.cn.

Filn has over 20 years of experience in Filn 4 pins 30A 12V momentary autozone rocker switch producing, and also a professional rocker switch R&D team. They can customize the rocker switch scheme for you within 24 hours. Filn has over 10 years of overseas sales experience, they can communicate and solve the international trade problem in time. If you have any questions about the rocker switch, please contact us, our email address is inquiry@cnylin.com.cn.

Product Item	KCD4-0112-21
Panel Mount Diameter	22*28mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

Product drawings

The features of the illuminated rocker switch.

The waterproof rating of the 24 volt illuminated rocker switch can reach IP67, it adopts imported rubber, it has quality assurance, it is not easy to damage for long time use and effective waterproof. The product’s current can reach 20A 250V. The regular connection way is plug in, while this type we use screw pin connection way.

The description of the 24 volt 20 AMP red LED waterproof illuminated rocker switch.

1.The mounting hole diameter of the red illuminated rocker switch is 22*30mm, the KCD4 product also has other size of 22*28mm. Its installation way is direct card buckle style. The hole size of the panel is 22*30mm, but the thickness should be between 0.8 and 4mm in order to ensure the waterproof effect.

2.The waterproof rating of the LED illuminated rocker switch reach IP67. Put the rocker switch’s transparent cover and waterproof cap on the rocker switch’s lamp base. This seal is formed through a waterproof cap, and the waterproof cap’s material is silicone, which is waterproof and oil-resistant and can be used on professional business kitchen equipment.

3.The 20 AMP illuminated rocker switch can achieve a variety of voltages, such as 3V, 6V, 12V, 24V, 48V, 110V, 220V, 380V,etc. We can achieve different voltages by changing the resistance. Among which, 12V, 24V, 220V is the hot selling products.

4.The illuminate rocker switch can achieve five colors of red, yellow, blue, green, white, the internal LED is nonpolar and regardless of the positive and negative poles. We can also produce the product without lamp.

5.The waterproof illuminated rocker switch of Filn had passed the certifications of CE, ROSH, ISO90001, etc. Some of the products had passed the UL certification.

6.The regular button printing is”O-” or “-O=” or “ON-OFF” , “ON-OFF-ON”, etc. The printing word is the information about Filn, voltage, logo, etc. We can customize other different symbols or logos.

7.The 24V red illuminated rocker switch mainly has the functions of ON-OFF 4 pins and 2 gears, ON-OFF-ON 6 pins and 3 gears, (ON)-OFF-(ON) double reset 3 gears and 6 pins, (ON)-OFF single reset 4 pins and 2 gears, ON-ON 6 pins and 2 gears, etc. The rocker switch in the picture has the function of ON-OFF 4 gears 2 pins.

8.The head of the 12v LED rocker switch adopts nylon PC material, lamp base and the rocker switch’s base also adopt nylon PA66 material, which is flame-retardant and high-temperature resistant. When the rocker switch is welded with wire pin, it won’t cause the rocker switch’s base to melt. The waterproof cap adopts silicone material, and metal pin adopts copper H62.

How to wire AC illuminated rocker switch?

There are two kinds of wiring: the first kind of wiring is to switch two lamp feet connected to the positive and negative poles of the power supply, switch two side feet connected to the equipment.Can keep the LED light in switch on. The second kind of wiring is to switch two side feet connected with the positive and negative poles of the power supply, switch two lamp feet connected with both ends of the equipment. This is a normal connection. As shown in figure and video.

What is LED illuminated rocker switch ?

LED illuminated rocker switch means the rocker switch has lamp inside, when it is energized, the light will bright up. We can judge the state of the rocker switch by the lamp’s state.

Where does the 24 volt illuminated rocker switch used?

The green 220V illuminated rocker switch mostly used in Drinking dispenser, treadmill, computer speaker, battery car, motorcycle, ion TV, coffee pot, row, massage machine, etc., mainly on home appliances and kitchen equipment.

How to purchase the 20AMP illuminated rocker switch?

You can purchase our products through online sales platform of Alibaba, or you can purchase the LED white rocker switch through offline email communication. Per weigh of the product is about 0.02kg, we will choose delivery way according to customer’s purchase quantity. 1000 pieces are packed in one carton, and the weight is 19kg. We can provide samples free of charge for your test.

The advantages of the waterproof illuminated rocker switch produces by Filn.

1.We’re a factory, so have sufficient material inventory and fast delivery. We have inventory of the conventional product. We can complete 1000 pieces conventional rocker switch within 3 days.

2.We have complete certifications, specifications and other information, and can be provided quickly.

3.Filn has a professional team of engineers to design rocker switch, and also has a team of engineers specializing in producing rocker switch mould, they can complete the design and mould development of the new rocker light switch between 30 to 40 days.

4.We have premium warranty service and after-sales service.

The push button switches of Filn have price competitiveness advantage in the same industry. It also has the most complete style. Yulin electronics guarantee its product quality and was praised by domestic and foreign customers. We will continue to R&D new push button switches and create a better image and brand power. If you need our product, or you’re interested in our product, or you want our samples, please contact us directly, our email address is inquiry@cnylin.com.cn.

Product Item	KCD4-0112-21
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

Product Drawings:

Product Parameters:

Product Item	KCD4-0122-23
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

Switch Wiring Method:

6 feet 3 gears with light on off on momentary rocker switch conventional wiring diagram

3 Way  six-pin waterproof rocker switch wiring mode: 1: Two pins are connected to the power supply, the other two pins (lamp pins) are connected to the device, the switch is pressed, the switch light is on, the device starts, the switch is off, the switch light is dark, and the device is closure. 2: Connect the two light pins to the power supply and the other two pins to the device to keep the switch light on. Press the switch to start the device, turn off the switch, and the device shuts down.

Applications:

• Industrial Applications
• Home Automation
• Automotive Integration
• Medical Devices
• Consumer Electronics
• Public Infrastructure
• Commercial Use
• Security Systems
• Hospitality Industry
• Transportation Use

Related products:

3 way rocker switch Product Introdution



This 6-pin high-current 3 way rocker switch is designed and developed by German customers. We met this manufacturer at the Munich Electronics Show in Germany, and he told us about the problems he encountered with the ship type switch he is currently using. I understand that the 3 way rocker switch is also imported from China, and all specifications of the 3 way rocker switch are in use.

Through our understanding of customers, we understand the following needs of customers:

1. Waterproof rocker switch is required, and 3 way, DPDT ON-OFF-ON is required.

2. The waterproof cap holster needs to be firmly stuck to the panel, and the holster cannot harden out after a long time.

3. The ship type switch requires a large current and can reach up to 30A.

4. The bottom plastic should be made of high-temperature resistant materials so that the terminal will not shake due to high temperature during soldering.

5. The ship type switch needs to complete the CE certification. If there is a VDE demand, the certification will be completed at an additional cost.

6.3 The way rocker switch needs built-in 250V LED lamp beads.

7. The tensile force of the waterproof leather case needs to reach 50N or more.

8. Because it is for household use, the bulb inside needs to be LED, which is more energy-saving and environmentally friendly.

9. The button of the rocker switch should be smooth when switching back and forth in the third gear, and there should be no jams or unclear gears.

On this basis, at the same time, the manufacturer’s monthly dosage is super large, and the price should be economical on the basis of quality assurance. Because this directly affects the cost of their entire product, profit, the amount of use of the modified product, and the marketing of distributors in various places.

For this reason, FILN decided to develop a cost-effective 3 way rocker switch for him for free. After the efforts of FILN R&D engineers, we improved this waterproof rocker switch after 2 weeks. The waterproof leather case is made of Dingqing silicon and plastic. The shell is made of brand new Gubyshev PA66 material. 3 way rocker switch with high current up to 30A.

This improved 3 way rocker switch solves the troubles of the guests before. After many samples were sent, the guests tested and observed many times. At the Shanghai International Hotel Exhibition, the guests flew over from Germany to meet with us. After confirming the product parameters, specifications, purchase quantity, and our production cycle. We signed the contract and paid the deposit on the spot.

So what exactly is this 3 way rocker switch? Everyone has been looking forward to it for a long time. The following is the detailed description of this improved 3 way rocker switch.

1. This 3 way rocker switch, the plastic shell is made of PA66 high temperature resistant nylon material, the material is brand new, and the waterproof leather case is made of Dingqing material.

2. The opening installation size of this improved 3 way rocker switch is 30x22mm, which is directly inserted into the installation panel, and there is also a smaller size 28x22mm for selection.

3. This 3 way rocker switch has built-in LED bulbs, and various voltages can be customized according to requirements, such as 12V, 110V, 220V, 230V, 250V, etc.

4. The contact point of this 3 way rocker switch is a 4 mm thick silver point, and the size of the solder foot is 6.3*0.8mm.

The following is the electrical diagram of this 3 way rocker switch and the introduction of the connection method:

This is this 3 way rocker switch has a total of six feet, divided into two rows, three feet in a row, as shown in the electrical diagram, the middle two feet are connected, and the upper and lower horizontal lines represent two groups respectively: one group (On) off, another group (on) off.

Another customer asked a question. We want to export this button switch to Germany. Do you have American CE certification or VDE certification?

Regarding the European CE certification, after 2 months of hard work by our team, this 3 way rocker switch has now obtained the European CE certification. Although the cost of completing various certifications is very high, in order to ensure the quality of our products, it has been For our own high requirements, our company’s products have successively completed UL, CE, RoHS, VDE. We are working hard to complete the German VDE certification for this 3 way rocker switch.

The following is the Q&A session of this 3 way rocker switch



1. What is the shelf life of this 3 way rocker switch?

The shelf life of this 3 way rocker switch is 3 years and the mechanical life is 10,000 times. If you have higher requirements, such as a mechanical life of 50,000 times, FILN can be customized as required. If you encounter any problems during the warranty period, you can write an email to contact FILN technical after-sales group inquiry@cnylin.com.cn, we will contact you immediately within 12 hours to solve any of your product quality problems and solutions.



2. What is the waterproof rating of this 3 way rocker switch?

This rocker switch designed with a waterproof cap has an IP65 waterproof rating. At the same time, we have completed a 3 way rocker switch with an IP68 waterproof rating. The IP68 is the waterproofing of the purchased leads at the tail, and then epoxy polyester encapsulation.



3.What is the rated voltage and current of the way rocker switch?

This one is 30A 250VAC, 50/60Hz.



4. What is the temperature resistance of this 3 way rocker switch?

This improved conventional temperature resistance is 85 degrees, if we need 125 degrees of material, we can customize production.



5. Where can I buy this 3 way rocker switch directly?

If you use less, you can go directly to FILN’s AliExpress website to buy, https://filn.aliexpress.com/store/414696, you can choose 15-20 days delivery express delivery, so that the freight is cheaper.



6. If you are in a factory and use this 3 way rocker switch extensively, you can write an email to contact the sales staff of FILN company sales2@filn.com.cn, the FILN sales team has more than 10 years of sales experience in foreign trade and Service, we will get back to you within 24 hours.

At the same time, we have distributors all over the world. If you want to get the products quickly, you can contact our local distributors.



7. Can FILN company customizes the ship type switch we need that is not available in the market?

FILN company has more than 10 professional button R&D engineers, who specialize in customizing various ship types with different styles and functions. As long as you need it, FILN company can provide various customized services.

Moreover, it only takes 30 days for a new switch from your idea to R&D design, the development of the abrasive tool to the completion of the finished product sample. FILN company can also provide OEM services, can be marked with your trademark and so on.

As long as you pay for the cost of mold and R&D for the ship type switch, FILN will only provide you with exclusive use and sales, which can greatly enhance your competitiveness and profit.



8. How about the price of this 3 way rocker switch?

This question is a very interesting question, you can only contact us for this question, but we promise to give you unexpected surprises, please contact us immediately inquiry@cnylin.com.cn.

Hot Product : signal indicator light lamp

120v ROCKER SWITCH,The biggest feature of the 120V rocker switch is that waterproof cap has plastic inside, it is more sealed and waterproof when installed on the panel.

Product drawings

What is a 20A ON OFF waterproof IP67 AC 120V rocker switch?

1.The mounting size of the 120V rocker switch is 30*22mm, and the installation way is buckle. You just need to open a hole of 30*22mm on the panel, then install 120V AC rocker switch into the hole, the ears on both sides of on off 120V rocker switch will jam the panel, it is very convenient to use. The panel thickness should be between 0.8 and 2mm. Please refer to 120V 4pins rocker switch wiring diagram.

2.The waterproof rating of 120V rocker switch is IP67, the seal was formed through a waterproof cap, the waterproof cap is made of silicone material, which is waterproof and oil-resistant, it can be used on the kitchen equipment.

3.The current of the 120V AC rocker switch is 20A, we can produce the product with the current of 15A and 30A.

4.The voltage of the rocker switch is between 3 and 220V, the common voltages are 3V, 6V, 12V, 24V, 110V, 120V, 220V, 250V. Among which 110V and 120V rocker switch is popular in US market while 220V and 250V rocker switch is popular in China market.

5.The 20A 120V rocker switch have 5 colors of red, green, yellow, blue, white. 120V red rocker switch is the most commonly used.

6.The service life of the IP67 120V rocker switch is 100,000 times with the power below 1,000W. If the power is higher than 1,000W, the service life will become shorten, while the power is below 500W, the service life will become longer.

7.The waterproof rocker switch of Filn had passed the certifications of UL, CE, ROSH. These international certifications demonstrate the product meet the international standards, ensuring the product’s quality. It can be sold and used in the US and European markets.

8.The head of the 120V waterproof rocker switch adopts nylon PC material, the lamp seat and switch base both adopt nylon PA66 material. It is flame-retardant and high-temperature resistant. When the rocker switch is welded with a wire lamp pin, the rocker switch base will not to melt. The waterproof cap adopts silicone material, and the metal pin adopts brass H62 material.

9.The rocker switch has three functions of on off, on on and on off on 120V rocker switch.

How do you wire a 120v rocker switch?

Firstly, connect the two side pins of the 120V rocker switch to the power’s positive and negative poles. Connect the two lamp pins to the device. Press 120 V rocker switch, the switch key light up, and the device starts. Press the switch again, LED is off and the device is closed. Under these wiring way, the switch is not normally bright.

How to buy a 120v rocker switch ?

You can purchase our product directly at www.cnfiln.com, or you can purchase the 120V rocker switch through offline communication, there is no MOQ. You can email us your requirement, our email address is inquiry@cnylin.com.cn.

The advantages of the 120V rocker switch of Filn?

1.There is no MOQ, we can provide the samples free of charge for your test.

2.Filn can provide customized services that can directly weld wires on the rocker switch, then directly connect the wiring.

3.The 120V rocker switch of Filn had passed the certifications of UL, CE, ROSH, ensuring the quality and consistency of the product.

4.Filn has a professional team of engineers who design the rocker switch, and also has a team of engineers specializing in producing rocker switch mould.

They can complete the product’s design and mould development within 30 to 40 days.

5.Filn’s sales staff are all sales engineers who can solve and respond to customer’s any questions regarding the rocker switch.

If you need our product or you’re interested in our product or need the samples, etc. Please contact us directly, our email address is inquiry@cnylin.com.cn.

Product Item	KCD4-0112-21
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

What is waterproof rocker switch ?
It designed based on normal rocker switch with waterproof function, so it can prevent the water from inside rocker switch when it used outdoor and water surface.
When start designing the rocker switch ?
FILN company began to product and design KCD4 waterproof switch series in 2016. It is very popular all over the world especially in the UAS market.
The introduction of KCD4 waterproof rocker switch series as follows :
How many kinds of voltage can the waterproof rocker switch have?
The range of voltage could be 3V,6v,12v,24v,36v,110v,220v,380v,440V.
What current of rocker switch can be reach ?
It has designed a high-current ship-type switch that could reach 30A at 12v and 250V. Its power can reach 5000W.
What is the size of the mounting hole of the rocker switch?
It has 3 sizes can be chosen, like 28X22, 30X22 ,31X22mm.
How about the waterproof degree of switch ?
It can be reach IP67 and IP68.
How many colors of switch ?
It can be made red, yellow,green, blue,white,black and orange etc. We also can use LED as the light source.
How many types of rocker switch for the use function ?
It has ON-OFF, ON-ON,ON-(OFF),ON-(ON),ON-OFF-(ON),(ON)-OFF-(ON) etc 7 function.
How many different styles are there on the surface of the rocker switch? Can the Rocker Switch be customized with a customer logo?
The rocker switch surface has stainless steel surface, painted surface, and plastic surface, and can support the customization of various logos on the rocker switch surface.
What international certifications are there for rocker switches?
Rocker switch has CE, UL, CQC, ROSH certification, etc.
Where are waterproof rocker switches usually used?
Waterproof rocker switch is used very widely, usually used in kitchen equipment, yacht equipment, automation equipment, electrical products, baby carriages, cars, motorcycles, refrigerator refrigeration, etc.
What is the MOQ of the rocker switch ?
FILN is a direct factory that produces waterproof switches, so there is no MOQ limit, and you can order from one.

Product Drawings:

Product Parameters:

Product Item	KCD4-0112-21
Panel Mount Diameter	22*30mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	15A, 20A, 30A

KCD4 waterproof Marine Toggle Switch is how to wire?

There are two types of wiring way of the product. The first type is that the side pins of the rocker waterproof switch are connected with the positive and negative pole of the power. The switch’s two light pins are connected with the device. When press the switch, the light guide key is bright, the device starts. Press the switch again, the light guide key is off, the device is closed. This is the wiring way that the light guide key is not often bright. Generally used in a light-normal environment.

The second type is that the two light pins are connected with the positive and negative poles, the switch’s two side pins are connected with the device. At this point, the switch light guide key is normally bright. The light guide key is always bright and is generally used in darker light environment. The wiring diagram is as follows.

FILN Marine Marine Toggle Switch Customization

What are the advantages of the 4 pin 12 volt 30AMP Marine Toggle Switch manufactured by Filn?

The waterproof rating of the waterproof Marine Toggle Switch can reach IP67.

The high rating Marine Toggle Switch can withstand high current and high power of 30A.

We had passed the certifications of UL, CE, it can be sold freely in the European and American markets.

The marine rocker switch has a reasonable price and is practical.

We provide 24-hour team service, if you have any technology, transportation, delivery date and other problems, we can reply to you quickly, making you have no after-sales worry.

We are a factory, giving you the product with high quality and low price.

Fast delivery, for the conventional products of the 12V Marine Toggle Switch，220V Marine Toggle Switch , 110V Marine Toggle Switch, we have regular inventory and material to meet the emergency demand.

We have 4 technical engineers with 20 years of R&D experience, providing professional solutions and design suggestions for customers to develop customized products.

Our company has heavy-duty laboratory, UL certified laboratory equipment, life test bench, temperature resistant test machine, aging test machine, microscope tester, tensile force tester, pressure resistance test table, etc. Use professional equipment to regularly sample and test the products, ensuring the safety and stability of each batch of products.

We have stable employees, and regular do staff process and safety equipment operation training.

Related products:

What are the parameters of the 4 pin 12 volt white 30AMP marine toggle switch panel?

The 4 pins 12 volt white 30AMP marine rocker switch is suitable for the marine rocker switch panel, which size is 0.8~4mm. You just need to open a hole of 30*22 on the switch panel and clutch it very smooth.

marina rocker switch The cover color of the marine rocker switch is untransparent black. Customers can also customize transparent covers with special requirements. Such as red, blue, green, yellow, white, these colors can be used to produce lighted marine rocker switch.

The features of the 4 pins marine rocker switch?

The unique waterproof frame design makes the waterproof level reach IP67. The material of purple copper and thick silver layer makes the switch’s rated power reach 30A/250V. The cover can be customized with printing. Besides, the product had passed the certifications of CE, UL, and exported to overseas. Quality is no problem, you can use it at ease.

Except for the O/I, the cover of the 4 pins marine rocker switch can be customized with the symbols of ON/OFF, START, ARROW TIP, etc.

The waterproof leather sheath of the 30AMP marine rocker switch is with a frame type. Making the rocker switch rubber and rocker switch fit closer. The silicone material is waterproof and oil-resistant, so the rating can reach IP67. This kind of switches can be used in kitchen equipment, yachts, cars, outdoor tools, etc.

The pin of the 12 volt white 30AMP marine rocker switch adopts the advanced purple copper material, composite large silver point of 3.5mm. It can be safely used on mechanical equipment with power below 5000W.

The plastic base of the 12 volt marine rocker switch adopts nylon double material, its temperature resistance can reach 260 degrees, ensuring that the rocker switch does not melt when the contact point is in contact with the heating plastic under the circumstance of large current. So it is suitable for the high-temperature device, such as water heater, electric blast furnace, chocolate machine, hairdryer, etc.

The service life of the marine rocker switch with the power of 5000 W is 100,000 times, if the power is high than 5000W, the service life becomes shorter, while the power is below 1000W, the service life becomes longer.

If the rocker switch is with light, it can achieve five colors of red, green, blue, yellow, white.

Our 4 pins rocker switch has the function of ON OFF, and it is DPST, it can be connected with two groups of circuits at most.

How to purchase the 4 pins 12 volt white 30amp marine rocker switch？

We have our own official website of www.indicatorlight.com ,you can email us regarding the required product and corresponding parameters, we will respond immediately.

We also have online sales platform, such as Aliexpress, Alibaba, Amazon, you can search Filn directly to find our store and place an order directly. If you have any questions, please contact our customer service staff on the relevant platforms, who will answer your questions in time.

Filn has 20 years of experience in rocker light switch producing, it also has a professional rocker switch R&D team, they can customize the rocker switch scheme that you need within 24 hours. Filn also has over 10 years of overseas sales experience, we can timely communicate and solve international trade problems. If you have any questions about the rocker switch, please contact us, our email address is inquiry@cnylin.com.cn.

Product Drawings:

Product Parameters:

Product Item	FL3-KCD3-0111-11
Panel Mount Diameter	19.5*13mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	5A

How to wire a marine rocker switch?

The structure of the marine rocker switch is simple. It has two levels of ON/OFF, as shown in the figure below. When the cover is pressed down, the device starts to work and the LED light is on.

FILN marine rocker switch Customization

The end of the marine rocker switch is fully sealed, which can effectively play a waterproof effect, and can be used normally for a long time in a wet environment.

FILN provides customized production service, from voltage to appearance to meet your needs.

Applications:

• Industrial Applications
• Home Automation
• Automotive Integration
• Medical Devices
• Consumer Electronics
• Public Infrastructure
• Commercial Use
• Security Systems
• Hospitality Industry
• Transportation Use

Related products:

Marine Rocker Switch Product Introduction



This marine rocker switch is a switch with a waterproof surface. A waterproof leather case is added to the original base, which makes it waterproof. Compared with the old waterproof cap, the waterproof leather case is more convenient to use and more beautiful.

Generally, we will pad print ‘ 0 ‘ , ‘ I ‘ on the marine rocker switch.
The ‘ I ‘ position represents the number ‘ I ‘, which means on, which is equivalent to the level signal on.The ‘ 0 ‘ position means the number ‘ 0 ‘, which means off, which is equivalent to the level signal off.

‘ I ‘ and ‘ 0 ‘ are generally marked on the two ends of the button of the ship type (rocker) switch. A more scientific design is to mark the word ‘ON’ on the ‘ I ‘ end of the switch installation position, and mark ‘OFF’ on the ‘ 0 ‘ end.

How to wire the marine rocker switch with lights on three legs?

The wiring method of the three-pin switch is shown in the figure, the middle pin is the com point, and the two sides: one is the NC (normally closed) point and the other is the NO (normally open) point.

The lamp is connected between pin 1 and pin 3. There are two ways of connection. One is to connect pin 2 and pin 3 together, so that when the switch is closed, the lamp is short-circuited and does not light up. When the switch is open, the lamp is connected. It lights up on the electrical appliances and the live wire to indicate that the switch is off.

Another connection method is to use a separate neutral wire to connect to pin 3, so that the light is on when the switch is closed, and it does not light when the switch is open, which acts as an indicator of electricity consumption.

Waterproof marine rocker switch water-proof performance judgment standard waterproof marine rocker switch is very popular in daily life. In many households, toilets and kitchens and other humid places are installed waterproof marine rocker switches. Waterproof rocker switch refers to a switch that can be operated with wet hands and can use electricity more safely.

Nowadays, there are many types of waterproof marine rocker switches on the market. Generally, mechanical operation switches refer to waterproof rocker switches. An extra waterproof cover is added to the outside of the switch to enhance safety. In the real sense, there are relatively few switches on the market that can be operated with wet hands, except for some major brands such as Siemens, which are internationally famous, and Narcoleptic of Elan tron.

Judging the performance of waterproof marine rocker switch can be judged according to three aspects.

1. Whether the certification is complete. Whether it contains ROHS, SGS, ENEC and other certifications, these are the certification requirements for high-quality waterproof rocker switches, and they are also required by the export customs.

2. The performance evaluation of the waterproof rocker switch is based on the IP waterproof grade standard. The highest waterproof grade of the current switch is IP68.

3. Some other criteria for judgment. The waterproof marine rocker switch has reasonable design, high temperature resistance, high current impact resistance, long service life and other factors that need to be considered.

The specific application of the waterproof rocker switch is also restricted by factors such as the installation method, the installation direction of the product, the airflow, and the working voltage.

For example, the waterproof marine rocker switch produced, which has a strong sealing performance, has reached the leading level, but it is still necessary to prevent the intrusion of corrosive gases or substances.

How to choose marine rocker switch?

I don’t know that the marine rocker switch has a power limit. If the heater, electric iron and other plug-ins are plugged into the same marine rocker switch, the marine rocker switch will be overloaded and heated, and the insulating material will also heat up and deteriorate, which may cause a fire. As the weather gets colder, marine rocker switch plays an important role in the lives of citizens, but if it is not selected properly, there will be safety hazards and unnecessary damage to family property and life safety. Therefore, the editor here reminds the general public to replace marine switches that do not comply with safety regulations as soon as possible to avoid safety accidents.

Pay special attention to the following six points when buying at the same time:

1. Choose a channel. When buying marine rocker switch, do not be greedy for cheap. It is recommended to buy it at a regular large chain supermarket, hypermarket or electrical appliance store, and keep the proof of purchase.

2. Recognize the brand. Pay attention to the monitoring and testing information released by the industry and commerce, quality inspection and other departments, as well as the comparative experiment results released by the consumer associations (consumer committees, consumer protection committees), and try not to choose brands that have been exposed and punished.

3. Look at the appearance. The manufacturer and product information on the qualified marine rocker switch packaging is complete, while some unqualified switches are simple in packaging and lack basic manufacturer and product information, especially the production date on the product packaging. Many inferior switch products do not. Indicate the production date on the packaging, which is usually unqualified. In addition, the shell panel of the qualified marine rocker switch is exquisitely made, the shell and the jack side have no burrs, the jack size is symmetrical and uniform, and the poor quality shell is rough in workmanship.

4. To the hole type. Do not buy the prohibited universal port marine rocker switch. Its three-phase jack and two-phase jack are combined, and there are three holes.

5. Count the bolts. Do not buy a two-core marine rocker switch with a three-pole jack on the plug-in board but only two pins on the plug that comes with the marine rocker switch itself.

6. Test the feel. It can be distinguished from the following four aspects: weigh the weight, repeatedly press the switch, try the plugging force, and pull the power cord.

(1) Weight: The marine rocker switch conforming to the national standard uses a lot of copper wires, thick copper sheets, and tight plastic shell, so the weight is heavier. If a substandard switch cut corners, the material will obviously be much lighter.

(2) Press the switch repeatedly: you can press it several times, the qualified products can be opened and closed freely, the sound is clear; the unqualified products will feel dull and easy to get stuck.

(3) Trial insertion and extraction force: A qualified marine rocker switch not only has a moderate and flexible feel for insertion and extraction of each hole, but also has the same insertion and extraction feel for each jack; the insertion and extraction force is too loose or too tight, poor elasticity and easy to loosen , The feel of each hole will be different.

(4) Pull the power cord: The power cord of the qualified marine rocker switch feels moderately soft and hard, and the connection with the marine rocker switch is solid and reliable. Unqualified power cords will feel soft, weakly connected, and easy to pull off.

Feiling marine rocker switch has passed UL, CE, ROHS and other certifications. The quality is guaranteed and lifelong after-sales. If you have any doubts or questions in the process of using our products, you can contact us directly. Regardless of whether you bought it from our distributors or other platforms, you can ask us.

Hot Product: Machine indicator light

Product drawings

Product Parameters:

Product Item	FL3-KCD3-0111-11
Panel Mount Diameter	11*28mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	NO LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	black
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	5A

How to wire a 2 prong rocker switch?



Since this waterproof black rocker switch has only 2 legs, the connection method is very simple.

One pin is connected to one pole of the power source, the other pin is connected to one pole of the device, and the other pole of the device is connected to the power source. A circuit controlled by the KCD3 2 prong rocker switch is formed, and the control circuit can be turned on and off by pressing the button. The connection method is very simple, the operation is simple, and everyone knows it.

FILN round rocker switch Customization

Advantages of Customization:

• Personalization: Symbols tailored to individual preferences.
• Customizable Voltage and Color: Tailored voltage and color options.
• Diverse Wiring Options: Multiple wiring methods to suit diverse needs.
• More Affordable Pricing: Cost-effective pricing choices.

Applications:

• Industrial Applications
• Home Automation
• Automotive Integration
• Medical Devices
• Consumer Electronics
• Public Infrastructure
• Commercial Use
• Security Systems
• Hospitality Industry
• Transportation Use

Related products:

FILN KCD3 15A 250V Waterproof 2 Prong Rocker Switch Product Introduction

1.Mounting aperture: This 2-pin 2 Prong Rocker Switch is a waterproof 2 prong rocker switch developed on the basis of an 11×28 ordinary rocker switch. Its mounting hole is 11x28mm. It is the same as the conventional one. It’s just more waterproof. The panel thickness should be below 0.8mm. As long as the FILN 2 prong rocker switch is stuck on the panel, the installation is successful, and the follow-up is a wiring problem.

2.Waterproof KCD3 2 prong rocker switch is a waterproof design. The waterproof grade of the rocker switch is IP67. It is made of the transparent cover of the rocker switch and the waterproof cap of the rocker switch is buckled on the lamp holder of the rocker switch, and the waterproof cap forms a seal. , The waterproof cap is made of silicone material, which is waterproof and oil-proof, and can be used on kitchen equipment.

3.Current: The current of AC BLACKE ROCKER SWITCH is 16A, and it can be used on mechanical equipment below 2000W under the condition of 120V. If you want 20A ROCKER SWITCH, you can change the side foot and middle foot of the rocker switch and the springboard by The brass is changed to red copper, and then the contact silver point is changed from 2.5MM to 3.5MM, so that the current of the ship switch can be increased. FILN can accept your needs to customize any achievable product.

4.Voltage: 250V 2 prong rocker switch is without light, but the 3-pin type is with light, it can be made in different colors, then the voltage can be 3v 12v 24v 36v 110v 220v 380v, this voltage we refer to the lamp Voltage.

5.Color: The luminous body in the waterproof 2 prong rocker switch is LED, so it can produce 5 colors of red, green, yellow, blue and white. This BLACK rocker siwtch is a waterproof rocker switch without lights.

6.Service life: 2 prong rocker switch can be used 100,000 times under the power of 2000W, if it is higher than 2000W, the service life will be shorter, if it is below 2000W, the service life will be longer.

7.Certification: FILN waterproof rocker switch has passed U.S. UL, CE ROSH and other certifications. These international certifications prove the international standards for various functional symbols of FILN 2 prong rocker switch and guarantee the quality of 250v 2 prong rocker switch. It can also be used in the United States. And sold and used in the European market.

8.Material: The head of the FILN 2 PRONG ROCKER SWITCH is made of nylon PC material, and the lamp holder and the rocker switch base are made of nylon PA66 material, which is flame-retardant and high temperature resistant. When the rocker switch is welded with wires and lamp feet, it will not cause The base of the boat-shaped Aqua is melted, the waterproof cap is made of silicone material, and the metal foot of the boat-shaped switch is made of brass H62.

9.Function: Black rocker switch can be ON OFF, ON OFF ON, and ON ON, of course, it can also be reset ON OFF. The non-lamp waterproof rocker switch ON OFF is 2-pin, and ON ON is 3-pin.

The ON OFF of the lighted model is 3-pin, and the ON OFF ON is also 3-pin.

What are the advantages of the 2 prong rocker switch produced by FILN?

1.There is no MOQ for the rocker light switch produced by FILN. No matter if you use a few or a few hundred, or order in bulk, we can accept it.

2.Accept customization. For example, if you want the rocker switch to be directly wired, FILN can provide customized services. You can directly solder the wire on the rocker switch, and you can directly connect it when you go back. Or equipped with corresponding terminal connectors, etc., can meet your needs.

3.The KCD3 2 prong rocker switch produced by FILN not only has UL, CE, ROSH and other international certifications, but all round rocker switches are produced in accordance with ISO9001 quality management system standards, ensuring product quality and consistency.

4.The development speed is fast. FILN has a professional team of engineers for R&D and design of rocker switches, as well as a team of engineers specializing in the production of rocker switch abrasives. The design of the 250v 2 prong rocker switch and the development of abrasives are basically completed within 30-40 days.

5.Quickly respond to ship-type switch issues. FILN’s sales staff are all sales engineers, and can respond to any customer’s questions about ship-type switches as quickly as possible.

2 Where are prong rocker switches used?

It can be used in many places, such as kitchen equipment, water dispensers, treadmills, computer speakers, battery cars, motorcycles, ion TVs, coffee makers, power strips, massage machines, and some industrial equipment. It has a wide range of uses.

How to buy this 2 prong rocker switch?

1.If you need to customize the Waterproof 2 prongrocker switch or have any other special requirements, such as wire bonding, how to use it, want to buy in bulk, etc., you can write an email to our button technical engineer Louis, and he will give you a satisfactory solution , His email is inquiry@cnylin.com.cn

2.If you need a large quantity, you can directly write an email to our international trade sales staff. They have more than 10 years of overseas sales experience and will give you good prices and quality services.

3.If you need a small amount of KCD3 2prong rocker switch, you can place an order directly on www.cnfiln.com, and FILN will ship it on the same day.

4.If you need samples for testing, FILN will provide samples for free.

Dual Rocker switch Product Introduction



The dual rocker switch is a waterproof model based on a dual rocker switch with a common 10x28mm mounting hole. This model can be used for ON OFF ON 3 gears, or ON OFF with light.

Or ON OFF ON with lights, all black is generally without lights, lights with lights are generally available on the buttons, different color buttons will have transparent colors, such as red lights with transparent red Button.

Our model can be made in 5 luminous colors, red, green, yellow, blue, white, and black are generally without lights. There are also some customers who want different button colors but without lights. We can also do this.

Regarding the voltage, we usually talk about the voltage of the lamp, which can be 12v, 24v, 110v, 220v, 380v, etc. Of course, some customers want 3v, 5v, 48v, etc. We can also customize it for them. We are a factory, which is very simple for us. .

At present, our dual rocker switch has passed the certifications of CE, UL and environmental protection certification.

Water can conduct electricity. In our daily life, it is inevitable that some water will splash in when we use the switch seat. This has a great potential for electricity use. Therefore, most people now use waterproof switches, which are waterproof dual. Rocker switch is one of them. So, if you buy a waterproof dual rocker switch? What are the precautions when we use the waterproof dual rocker switch in the future?

Waterproof dual rocker switch, as the name suggests, is a dual rocker switch that can be used in the environment or can be operated with wet hands.

Waterproof dual rocker switch, there are other names, such as: wave switch, rocker switch, rocker switch, rocker switch, IO switch, power switch, because the rocker switch looks like a ship, so it is called this way.

Waterproof dual rocker switch has a wide range of applications, such as water dispensers, coffee pots, rice cookers, kettles, etc. For now, there are many brands and types of waterproof dual rocker switches on the market

Top ten dual rocker switch brands

1: TCL-Legrand (China’s well-known trademark, TCL-Legrand International Electric (Huizhou) Co., Ltd.);

2: Simon switch socket (Spain in 1916, the world famous brand of communication wiring, Simon Electric China Co., Ltd.);

3: Siemens (started in 1847 in Germany, the world’s largest electrical and electronic company);

4: Panasonic (China’s well-known trademark, Japan’s Matsushita Electric (China) Co., Ltd.);

5: Schneider (one of Schneider Electric’s preferred brands in the global power distribution field, Tianjin Merlin Rilan Electric Group);

6: Fudao Switch (founded in Zurich, Switzerland in 1937, the world-renowned electrician brand, Fudao Group);

7: Honeywell-Lonon (Guangdong famous brand, Honeywell Lonon Electrical System Technology (Guangdong) Co., Ltd.);

8: LOVOV switch socket (first-line brand/brand, Guangdong Zhongshan Luofu Group);

9:Matsumoto SOBEN (Guangdong famous trademark, Matsumoto Electric Industrial Co., Ltd.)

10: In the future of FILN Electronics, although we have a little gap with these companies, we believe that we have been close to them.

The dual rocker switch connects and disconnects the circuit by alternately pressing the two ends of the operating button like a rocker. It is usually used to turn on and off the main power of the device.

Since the action of the operation button is regarded as shaking up and down, the English word “rock” is regarded as “shake” and is called a rocker switch. Sometimes it is more directly called a rocker switch.

The dual rocker switch product line is divided into multiple types according to the opening and closing current value, the number of circuits and the external dimensions. There are also products with sealing and resetting functions.

Generally speaking, dual rocker switches tend to have higher on/off current values ​​and larger sizes. However, the manufacturer has independently improved the switching mechanism to produce a small but large current switching product.

Since the state of the operation button directly indicates the on/off state, if the operation button is activated/deactivated, it can be visually confirmed to avoid malfunction.

The dual rocker switch is divided into three types according to the rated current value (the upper limit of the opening and closing current value), which is divided into three types: 10, 16, and 20A, and its size also changes with the rated current value.

Specifically, from the perspective of the operation buttons protruding from the surface when the panel is installed, product 10a is 15mm×21mm, product 16a is 15mm×21mm, product 17mm×24mm or 25 mm×32mm, and product 20a is 27mm×37mm.

Product 16A has three sizes, but it used to be 25 mm x 32 mm. Now, miniaturization has been achieved using the above-mentioned switching mechanism. In addition, there are a variety of products that can be turned on/off with two buttons, the product can be illuminated with an operation button, and the product has a reset function and can be automatically turned on by an external signal.

During work, sometimes the dual rocker switch needs to be soldered, so can the dual rocker switch be soldered to the PCB?

The dual rocker switch is usually installed on the operation panel, so it is usually not necessary to arrange it on the PCB. The central plastic partition is configured to avoid short circuits in the wiring (there is a tendency to move or open and close the panel).

Since there are four plastic snap points glued on the mounting panel, it is only necessary to make square openings of the same size on the panel. If you need to install a dual rocker switch on the PCB, you only need the size drawing of the component mechanism to make it correspond to the corresponding slot on the PCB.

Like other plug-ins, the corresponding line can be routed to the corresponding terminal. This type of electromechanical component is related to the shape of the product. The installation method of the components meets the structural requirements and can be installed according to the requirements of the structural engineer.

Feiling dual rocker switch has passed UL, CE, ROHS and other certifications. The quality is guaranteed and life-long after-sales. If you have any doubts or questions in the process of using our products, you can contact us directly. Regardless of whether you bought it from our distributors or other platforms, you can ask us.

More FILB popular product: push button momentary switch

Product Drawings:

Product Parameters:

Product Item	KCD1-1211-11_012BR
Panel Mount Diameter	19.5*19.5mm
Contact Way	solder pin
Install Way	Buckle
Lamp Type	LED
Rated voltage	3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color	Red,white,blue,green,black,yellow
Shell Material	brass plated nickel
Base Material	PA66 nylon
Terminal Material	brass
Applications	Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current	5A

How do you wire a red kcd1 rocker switch?

Firstly, connect the pin’s one end of the red kcd1 rocker switch to the power, the other side’s pin of the rocker switch is connected to the device’s one end, then the one end of the device is connected to the power, it is the way of series connection.

When the device is energized, press the tab “o” on the lighted kcd1 rocker switch, then confirm the LED light of the kcd1 rocker switch is on or off.

Then confirm if the device is starting or not. If the device starts up means the connection was successful.

How does a kcd1 rocker switch work?

The rocker switch is divided into kcd1 rocker switch and rocker switch without lamp. The kcd1 rocker switch is installed on the device’s panel, controlling the machine’s startup and disconnection.

When the machine is energized, press down the power, the rocker switch’s light is on, or you press the tab “o” of the kcd1 rocker switch, the lamp inside the rocker switch is on, it means that the rocker switch is energized, the machine and equipment are powered up normally, and the machine can start safely.

Press the tab “-” on the surface of the rocker switch, the light is off inside the rocker switch, which means the machine and equipment have been disconnected.

The rocker switch without a lamp means it has no light-on function, it can only have the function as one switch.

FILN kcd1 rocker switch Customization

What is the advantage of the kcd1 rocker switch of Filn?

1. The rocker light switch of Filn has no MOQ, you can purchase from one piece, besides, the custom rocker switch has no MOQ, supposing you need one white 12 V rocker switch, Filn can produce.

2. If you want the rocker switch with wire, Filn can supply the customized service, the wire can be welded directly on the rocker switch.

3. The old rocker switch of Filn had passed the certifications of UL, CE, RoSH, and all the round rocker switches are produced according to the ISO90001 quality management system standards.

They can ensure the consistency of the product’s quality.

4. The new rocker switch has fast development speed, Filn has a professional R&D design team and engineers for producing rocker switch grinders.

The design and mould development of the new rocker light switch are basically completed within 30-40 days.

5. Reply to the problems about rocker switch in time, Filn’s sales staff are all sales engineers.

They can answer and solve any customer problems regarding the rocker switch in the shortest time.

6. Filn has 20 years of experience in producing rocker light switch, and also has a professional rocker switch R&D team, providing various rocker switch solutions for customers within 24 hours.

Filn also has more than ten years of overseas sales experience, and can communicate and solve international trade issues independently and timely, if you have any questions about the product, please contact us immediately, our email address is inquiry@cnylin.com.cn.

Applications:

• Industrial Applications
• Home Automation
• Automotive Integration
• Medical Devices
• Consumer Electronics
• Public Infrastructure
• Commercial Use
• Security Systems
• Hospitality Industry
• Transportation Use

Related products:

What is a kcd1 rocker switch?

Rocker light switch means the rocker switch is with lamp, the light is on when the rocker switch is on, we can judge the state of the rocker switch by lighting the light.

The advantage of the red power switch produced by Filn is waterproof, it can be used outdoors and where rain comes in.

The detailed description of the 3 way 12 volt red LED round illuminated rocker light switch.

1. The mounting hole size:

The mounting hole size of the 12V lighted rocker switch is 19.5mm, and its installation way is direct card buckle, you just need to open the hole of 20mm on the rocker switch panel.

Please note that the thick of the panel is between 0.8mm-2mm. Position the round rocker light switch at the mounting port of the rocker switch panel, plastic pieces on both sides of the rocker light switch get stuck on the boat switch panel.

The rocker switch is fixed, and installation is very convenient.

2. Waterproof:

The red power switch is designed with waterproof, the waterproof rating is IP67, put the transparency cover of the rocker switch and the waterproof cap of the lighted rocker switch on the lamp seat of the rocker switch, waterproof cap make the product sealed.

The material of the waterproof cap is silicone material, it is waterproof and oil-resistant, it can be used on the kitchen equipment in a lampblack environment.

3. Current:

The current of the illuminated rocker light switch is 5A, under the voltage of 250V, it can be used on the mechanical equipment of which power is below 1000W.

If you want to the 10A rocker switch, you can change the material from brass to purple brass(⑨⑩⑦), then change the size of the contact silver points from 2.5mm to 3.5mm.

4. Voltage:

Through changing the resistance of the small rocker light switch to customize a variety of different voltages, such as 3V, 6V, 12V, 24V, 110V, 120V, 220V, 250V, etc. Among these, the 12V voltage rocker light switch is the most commonly used.

5. Color:

The illuminant body inside the old rocker switch is LED, it can achieve five colors of red, green, yellow, blue, white, if you need a black rocker switch, that is the rocker switch without the lights, the surface is black and does not shine.

6. Service life:

The service life of the marine lighted rocker switch is 100000 times at a power level of 1000W. If the power level is higher than 1000W, the service life becomes shorter, while under 500W, the service life becomes longer.

7. Certification:

The waterproof rocker switch of Filn had passed the certifications of UL, CE, ROSH.

They can prove that the functions of product meet the international standards, ensuring the quality of the 3 way rocker light switch, it can be sold and used in the US and European markets.

8. Material:

The head of the lighted 3 way rocker switch adopts the nylon PC material, the lamp seat and base are of nylon PA66 material, it is a flame-retardant and high-temperature-resistant material.

This can prevent the circumstance that welding of wires and lamp feet caused the rocker switch’s base to melt. The waterproof cap is made of silicone material, the rocker switch’s metal pin adopts the copper H62 material.

9. Function:

The marine red power switch has the functions of ON-OFF and reset ON-OFF.

How to buy a red power switch?

The red power switch has many voltages, such as 12V rocker light switch, 120V rocker light switch, etc.

You can email us directly, please indicate the information of voltage, current, color, and usage environment.

We can recommend the most suitable rocker switch to you, our email address is inquiry@cnylin.com.cn.

If you need the common rocker switch, such as KCD4 rocker switch, KCD1 waterproof rocker switch, you can click on this link www.cnfiln.com ,you can place an order in our store, we will arrange the delivery within 24 hours.
