3 Way Rocker Switch 110V 15A Yellow LED ON OFF ON Momentary

  • Name:3 Way Rocker Switch
  • Model: KCD4-0122-23
  • Panel Mount Diameter:22*30mm
  • Rated Voltage:15A, 20A, 30A
  • Voltage Options:3V, 5V, 6V, 12V, 24V,13V, 110V, 120V, 220V, 240V, 250V, 380V
  • Color:Red, White, Blue, Green, Yellow, Black
  • Material:ABS plastic, Stainless Steel
  • Download Certification:CECCC, ROSH, IP67, UL
  • Waterproof grade:IP67
  • Email:
  • Download PDF: KCD4-0122-23规格书

Product Drawings:

110v 15A YELLOW LED ON OFF ON momentary kcd4-202n 6 pin ul rocker switch

Product Parameters:

Product Item KCD4-0122-23
Panel Mount Diameter 22*30mm
Contact Way solder pin
Install Way Buckle
Lamp Type LED
Rated voltage 3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color Red,white,blue,green,black,yellow
Shell Material brass plated nickel
Base Material PA66 nylon
Terminal Material brass
Applications Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current 15A, 20A, 30A

Switch Wiring Method:

6 feet 3 gears with light on off on momentary rocker switch conventional wiring diagram

3 Way  six-pin waterproof rocker switch wiring mode: 1: Two pins are connected to the power supply, the other two pins (lamp pins) are connected to the device, the switch is pressed, the switch light is on, the device starts, the switch is off, the switch light is dark, and the device is closure. 2: Connect the two light pins to the power supply and the other two pins to the device to keep the switch light on. Press the switch to start the device, turn off the switch, and the device shuts down.

3 Way Rocker Switch 110V 15A Yellow LED ON OFF ON Momentary

FILN 3 way rocker switch Customization

The end of the 3 way rocker switch is fully sealed, which can effectively play a waterproof effect, and can be used normally for a long time in a wet environment.

FILN provides customized production service, from voltage to appearance to meet your needs.


  • Industrial Applications
  • Home Automation
  • Automotive Integration
  • Medical Devices
  • Consumer Electronics
  • Public Infrastructure
  • Commercial Use
  • Security Systems
  • Hospitality Industry
  • Transportation Use
3 Way Rocker Switch 110V 15A Yellow LED ON OFF ON Momentary

Related products:

3 way rocker switch Product Introdution


This 6-pin high-current 3 way rocker switch is designed and developed by German customers. We met this manufacturer at the Munich Electronics Show in Germany, and he told us about the problems he encountered with the ship type switch he is currently using. I understand that the 3 way rocker switch is also imported from China, and all specifications of the 3 way rocker switch are in use.

Through our understanding of customers, we understand the following needs of customers:

1. Waterproof rocker switch is required, and 3 way, DPDT ON-OFF-ON is required.

2. The waterproof cap holster needs to be firmly stuck to the panel, and the holster cannot harden out after a long time.

3. The ship type switch requires a large current and can reach up to 30A.

4. The bottom plastic should be made of high-temperature resistant materials so that the terminal will not shake due to high temperature during soldering.

5. The ship type switch needs to complete the CE certification. If there is a VDE demand, the certification will be completed at an additional cost.

6.3 The way rocker switch needs built-in 250V LED lamp beads.

7. The tensile force of the waterproof leather case needs to reach 50N or more.

8. Because it is for household use, the bulb inside needs to be LED, which is more energy-saving and environmentally friendly.

9. The button of the rocker switch should be smooth when switching back and forth in the third gear, and there should be no jams or unclear gears.

On this basis, at the same time, the manufacturer’s monthly dosage is super large, and the price should be economical on the basis of quality assurance. Because this directly affects the cost of their entire product, profit, the amount of use of the modified product, and the marketing of distributors in various places.

For this reason, FILN decided to develop a cost-effective 3 way rocker switch for him for free. After the efforts of FILN R&D engineers, we improved this waterproof rocker switch after 2 weeks. The waterproof leather case is made of Dingqing silicon and plastic. The shell is made of brand new Gubyshev PA66 material. 3 way rocker switch with high current up to 30A.

This improved 3 way rocker switch solves the troubles of the guests before. After many samples were sent, the guests tested and observed many times. At the Shanghai International Hotel Exhibition, the guests flew over from Germany to meet with us. After confirming the product parameters, specifications, purchase quantity, and our production cycle. We signed the contract and paid the deposit on the spot.

So what exactly is this 3 way rocker switch? Everyone has been looking forward to it for a long time. The following is the detailed description of this improved 3 way rocker switch.

1. This 3 way rocker switch, the plastic shell is made of PA66 high temperature resistant nylon material, the material is brand new, and the waterproof leather case is made of Dingqing material.

2. The opening installation size of this improved 3 way rocker switch is 30x22mm, which is directly inserted into the installation panel, and there is also a smaller size 28x22mm for selection.

3. This 3 way rocker switch has built-in LED bulbs, and various voltages can be customized according to requirements, such as 12V, 110V, 220V, 230V, 250V, etc.

4. The contact point of this 3 way rocker switch is a 4 mm thick silver point, and the size of the solder foot is 6.3*0.8mm.

The following is the electrical diagram of this 3 way rocker switch and the introduction of the connection method:

3 Way Rocker Switch 110V 15A Yellow LED ON OFF ON Momentary

This is this 3 way rocker switch has a total of six feet, divided into two rows, three feet in a row, as shown in the electrical diagram, the middle two feet are connected, and the upper and lower horizontal lines represent two groups respectively: one group (On) off, another group (on) off.

Another customer asked a question. We want to export this button switch to Germany. Do you have American CE certification or VDE certification?

Regarding the European CE certification, after 2 months of hard work by our team, this 3 way rocker switch has now obtained the European CE certification. Although the cost of completing various certifications is very high, in order to ensure the quality of our products, it has been For our own high requirements, our company’s products have successively completed UL, CE, RoHS, VDE. We are working hard to complete the German VDE certification for this 3 way rocker switch.

The following is the Q&A session of this 3 way rocker switch


1. What is the shelf life of this 3 way rocker switch?

The shelf life of this 3 way rocker switch is 3 years and the mechanical life is 10,000 times. If you have higher requirements, such as a mechanical life of 50,000 times, FILN can be customized as required. If you encounter any problems during the warranty period, you can write an email to contact FILN technical after-sales group, we will contact you immediately within 12 hours to solve any of your product quality problems and solutions.


2. What is the waterproof rating of this 3 way rocker switch?

This rocker switch designed with a waterproof cap has an IP65 waterproof rating. At the same time, we have completed a 3 way rocker switch with an IP68 waterproof rating. The IP68 is the waterproofing of the purchased leads at the tail, and then epoxy polyester encapsulation.


3.What is the rated voltage and current of the way rocker switch?

This one is 30A 250VAC, 50/60Hz.


4. What is the temperature resistance of this 3 way rocker switch?

This improved conventional temperature resistance is 85 degrees, if we need 125 degrees of material, we can customize production.


5. Where can I buy this 3 way rocker switch directly?

If you use less, you can go directly to FILN’s AliExpress website to buy,, you can choose 15-20 days delivery express delivery, so that the freight is cheaper.


6. If you are in a factory and use this 3 way rocker switch extensively, you can write an email to contact the sales staff of FILN company, the FILN sales team has more than 10 years of sales experience in foreign trade and Service, we will get back to you within 24 hours.

At the same time, we have distributors all over the world. If you want to get the products quickly, you can contact our local distributors.


7. Can FILN company customizes the ship type switch we need that is not available in the market?

FILN company has more than 10 professional button R&D engineers, who specialize in customizing various ship types with different styles and functions. As long as you need it, FILN company can provide various customized services.

Moreover, it only takes 30 days for a new switch from your idea to R&D design, the development of the abrasive tool to the completion of the finished product sample. FILN company can also provide OEM services, can be marked with your trademark and so on.

As long as you pay for the cost of mold and R&D for the ship type switch, FILN will only provide you with exclusive use and sales, which can greatly enhance your competitiveness and profit.


8. How about the price of this 3 way rocker switch?

This question is a very interesting question, you can only contact us for this question, but we promise to give you unexpected surprises, please contact us immediately
