30 AMP 12V On Off Waterproof Panel White LED Rocker Switch
- Mode: KCD4-0124-21
- Voltage: 3V, 5V, 6V, 12V, 24V,13V, 110V, 120V, 220V, 240V, 250V, 380V
- Color: Red, White, Blue, Green, Yellow, Black
- Keywords: LED Rocker Switch
- Material: Stainless Steel
- Certification: CE CCC ROSH IP67 UL
- Waterproof grade: IP67
- Email: inquiry@cnylin.com.cn
- Download PDF: Stainless Steel LED 30A KCD4 12V ON-OFF 4Pins IP67 Electrical Rocker Switch
What is a 30AMP 12V on off LED rocker switch?
The LED rocker switch is suitable for water dispenser, treadmill, computer speaker, battery car, motorcycle, ion TV, coffee machine, power board, massage machine, etc.
The power switches used for our household appliances are basically LED rocker switch.
1.The mounting size of the 12V LED rocker switch is 30*22mm, the installation mode is a buckle. You just need to open a mounting hole of 30*22mm, and then put the LED rocker switch into the mounting hole, the ears on both sides of the LED rocker switch will jam the panel. It is very convenient to use, the panel thickness should be between 0.8 to 2mm.
2.The waterproof rating of the LED rocker switch is IP67, through a waterproof cap inform the seal, and the waterproof cap adopts silicone material, it is waterproof and oil prevention and can be used on the machine equipment.
3.The current of the LED rocker switch is 30A, we can also provide the product with the current of 15A and 20A.
4.The voltage range of the LED rocker switch is 3 to 220V, the common voltages are 3V, 6V, 12V, 24V, 110V, 120V, 220V, 250V.
5.The LED rocker switch can achieve five colors of red, green, yellow, blue, white.
1.The service life of the LED rocker switch is 100,000 times with the power of 1,000W. If the power is higher than 1,000W, the service life will become shorter, while the power is below 500W, the service life will become longer.
2.The LED rocker switch of Filn had passed the certifications of UL, CE, ROSH, etc. These international certifications demonstrate that the product’s functions meet the international standards. It also ensure the quality of the 30AMP 12V on off LED rocker switch, it can be sold and used in the US and European markets.
The key of the LED rocker switch adopts 304 stainless steel, it is mill-resistant and corrosion resistant. The lamp base and the switch’s base adopt nylon PA66 material, it is flame-retardant and high-temperature resistant. When the rocker switch is welded with a wire lamp pin, it won’t cause the rocker’s base to melt. The waterproof cap adopts silicone material and the metal pin of the rocker switch adopts copper H62 material.
3.The LED rocker switch has three functions of on off, on on and reset on off.
How to connect the rocker switch with LED?
Firstly, connect the two side pins with the positive and negative poles of power, then two light pins are connected with the device. When press the LED rocker switch, the switch key light up and the device starts. Press the switch again, the rocker switch’s LED is off and the device is closed. The switch does not often bright with the wiring mode.
How to buy a LED rocker switch ?
You can purchase our product directly from the online store of Alibaba, or you can buy the LED rocker switch through offline email communication. There is no MOQ requirement. 50 pieces of rocker switch are packed in one box, and 1000 pieces are packed in one carton, the weighty of 50 pieces product is 1.5kg.
The advantages of the 30AMP 12V on off LED rocker switch.
1.There is no MOQ for the LED rocker switch of Filn, we can provide the samples free of charge for your test.
2.Filn can provide customized service, and weld the wire directly on the rocker switch. Follow-up directly wiring.
3.The LED rocker switch of Filn had passed the certifications of UL, CE, ROSH, etc, ensuring the product’s quality and consistency.
4.Filn has a professional team of engineers to design rocker switch, and also has a team of engineers specializing in producing rocker switch moulds. They can basically complete new product’s design and mould development within 30 to 40 days.
5.Filn’s sales staff are all sales engineers who can solve and respond to any customer questions about the rocker switch at the fastest possible time.
If you need our product, or you are interested in our products, or you want to the samples, please contact us directly. Our email address is inquiry@cnylin.com.cn.
Product Item | KCD4-0124-21 |
Panel Mount Diameter | 22*30mm |
Contact Way | solder pin |
Install Way | Buckle |
Lamp Type | LED |
Rated voltage | 3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v |
Lamp Color | Red,white,blue,green,black,yellow |
Shell Material | brass plated nickel |
Base Material | PA66 nylon |
Terminal Material | brass |
Applications | Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc |
Current | 15A, 20A, 30A |
