Filn 4 Pins 30A 12V Momentary Autozone Rocker Switch

Product drawings

The features of the momentary autozone rocker switch.

The momentary autozone rocker switch is a self-reset autozone rocker switch. Meanwhile, its waterproof cover is made with a hard plastic frame, clutched on the panel hole, the waterproof effect is better. The overall appearance looks more three-dimensional. Interior use a large contact, and the maximum current can up to 30A 250VAC.

The description of the Filn 4 pins 30A 12V momentary autozone rocker switch.

1.The open hole size of the product’s panel is 30*28mm, its structure is 2 gears of off-on and the connect pin’s size is 6.3*0.8mm. Its material is nickel-plated, having better corrosion resistance and oxidation resistance.

2.The cover of the autozone rocker switch adopts PC material. Its high light transmittance makes the lamp light up more beautiful, and his temperature resistance makes the product durable. The cover has the colors of red, green, yellow, blue, white, black. The common printing of the cover is “I O”，it means (ON)-OFF, we can also print other symbols according to your requirement.

3.The autozone rocker switch is lighted or without lamp. The LED lamp can achieve the colors of red, green, yellow, blue, white, meanwhile it has a variety of voltages, such as 3V, 5V, 6V, 12V, 24V, 48V, 110V, 220V, 250V. We can provide 380V of three-phase electricity.

4.The current of the autozone rocker switch is 30A 250VAC, the diameter of the interior contact is 4.0mm, and the thickness is 0.2mm, its material is silver contact, the drawboard and connect pin both adopt copper plated nickel.

5.The base of the autozone rocker switch adopts PA66 strengthen nylon, its maximum temperature resistance can reach 260 degrees, and it is more secure in use since it is a flame-retardant material.

6.The autozone rocker switch is clutched on the hole of 30*22mm, and the panel’s thickness should be between 2 to 5mm, the installation is simple and fast.

The advantages of Filn 4 pins autozone rocker switch.

The material of the 4 pins autozone rocker switch adopts brand new nylon PA66 material, its shell color is yellow, this can make the product has a longer service life. In a low temperature environment, the shell is not easy to crack, meanwhile it is high-temperature resistant and fireproof. The interior is a 4.0mm large silver point, which is not easy to produce sparks after a long time use, and is more safe. We can provide different voltages and colors product to meet customer’s requirements.

How to wire a 30A autozone rocker switch?

The following is a brief wiring diagram of the 30A autozone rocker switch. When press down the rocker switch’s key, the lamp will light up, device starts to work. When release your hand, device is power off and the light is off.

How to buy a 12V autozone rocker switch?

50 pieces of products are packed in one box, 1000 pieces are packed in one carton, the weight of 50 pieces of products is 2kg. If you need a small amount of autozone rocker switch, you can place an order at www.cnfiln.com, we have inventory and can arrange the delivery as soon as receiving your order.

If you want to customize product or need the surrounding supporting wiring harness, you can list your requirements, such as connecting the wiring in advance, or install the custom quick connection terminals, or special voltages. Then email us, our email address is inquiry@cnylin.com.cn.

Filn has over 20 years of experience in Filn 4 pins 30A 12V momentary autozone rocker switch producing, and also a professional rocker switch R&D team. They can customize the rocker switch scheme for you within 24 hours. Filn has over 10 years of overseas sales experience, they can communicate and solve the international trade problem in time. If you have any questions about the rocker switch, please contact us, our email address is inquiry@cnylin.com.cn.
