3 Way 12 Volt Red LED Round illuminated Red Power Switch

  • Name:Kcd1 Rocker Switch
  • Model: KCD1-1211-11_012BR
  • Panel Mount Diameter:19.5*19.5mm
  • Rated Voltage:5A
  • Voltage Options:3V, 5V, 6V, 12V, 24V,13V, 110V, 120V, 220V, 240V, 250V, 380V
  • Color:Red, White, Blue, Green, Yellow, Black
  • Material:ABS plastic, Stainless Steel
  • Download Certification:CECCC, ROSH, IP67, UL
  • Waterproof grade:IP67
  • Email:
  • Download PDF: 3 way 12 volt red led round illuminated rocker light switch

Product Drawings:

rocker light switch drawings

Product Parameters:

Product Item KCD1-1211-11_012BR
Panel Mount Diameter 19.5*19.5mm
Contact Way solder pin
Install Way Buckle
Lamp Type LED
Rated voltage 3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color Red,white,blue,green,black,yellow
Shell Material brass plated nickel
Base Material PA66 nylon
Terminal Material brass
Applications Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current 5A

How do you wire a red kcd1 rocker switch?

Firstly, connect the pin’s one end of the red kcd1 rocker switch to the power, the other side’s pin of the rocker switch is connected to the device’s one end, then the one end of the device is connected to the power, it is the way of series connection.

When the device is energized, press the tab “o” on the lighted kcd1 rocker switch, then confirm the LED light of the kcd1 rocker switch is on or off.

Then confirm if the device is starting or not. If the device starts up means the connection was successful.

How does a kcd1 rocker switch work?

The rocker switch is divided into kcd1 rocker switch and rocker switch without lamp. The kcd1 rocker switch is installed on the device’s panel, controlling the machine’s startup and disconnection.

When the machine is energized, press down the power, the rocker switch’s light is on, or you press the tab “o” of the kcd1 rocker switch, the lamp inside the rocker switch is on, it means that the rocker switch is energized, the machine and equipment are powered up normally, and the machine can start safely.

Press the tab “-” on the surface of the rocker switch, the light is off inside the rocker switch, which means the machine and equipment have been disconnected.

The rocker switch without a lamp means it has no light-on function, it can only have the function as one switch.

FILN kcd1 rocker switch Customization

What is the advantage of the kcd1 rocker switch of Filn?

FILN has no MOQ

1. The rocker light switch of Filn has no MOQ, you can purchase from one piece, besides, the custom rocker switch has no MOQ, supposing you need one white 12 V rocker switch, Filn can produce.

Customized production of rocker switch

2. If you want the rocker switch with wire, Filn can supply the customized service, the wire can be welded directly on the rocker switch.

Rocker switch certification

3. The old rocker switch of Filn had passed the certifications of UL, CE, RoSH, and all the round rocker switches are produced according to the ISO90001 quality management system standards.

They can ensure the consistency of the product’s quality.

Development of a new rocker switch

4. The new rocker switch has fast development speed, Filn has a professional R&D design team and engineers for producing rocker switch grinders.

The design and mould development of the new rocker light switch are basically completed within 30-40 days.

Solve the problem of rocker switch

5. Reply to the problems about rocker switch in time, Filn’s sales staff are all sales engineers.

They can answer and solve any customer problems regarding the rocker switch in the shortest time.

Ship type switch overseas sales

6. Filn has 20 years of experience in producing rocker light switch, and also has a professional rocker switch R&D team, providing various rocker switch solutions for customers within 24 hours.

Filn also has more than ten years of overseas sales experience, and can communicate and solve international trade issues independently and timely, if you have any questions about the product, please contact us immediately, our email address is
