RJ9 Connector Telephone Plug Switch 19MM Easy Plug Button

What is RJ9 Connector？

According to the performance of the market, RJ9 connector is a type of connector commonly used in telephones.

Which is also known as 4P4C (4 Position 4 Contact Point) connector.

RJ stands for Registered Jack, which is a series of specifications and standards developed by the American Telecommunications Industry Association.

Now it is possible to combine the rj9 connector with a pushbutton switch to form the rj9 connector pushbutton switch product.

The Difference Between RJ9 and RJ11

RJ9 connectors are actually similar in appearance and function to RJ11 connectors, but there is a fundamental difference in the internal structure.

Usually RJ9 connectors have four metal contacts that are used to connect a telephone set or headset to a telephone device. These contacts are typically used to transmit audio signals as well as call control signals.

RJ9 connectors usually use modular design ideas, there are obvious rj9 access points on the product, which can be easily inserted into the appropriate slot or jack. It is widely used in a number of specific devices or products.

FILN reminds you that you need to pay attention to the fact that although RJ9 connectors are similar to RJ11 connectors, they have different contact point layouts and uses.

Before you purchase please make sure the product model number to ensure proper function and compatibility of rj9 connector push button switch.

Description of 19mm RJ9 Connector Switch

Introducing our new product, a telephone with a specially molded 19mm mounting hole size, designed for global distribution. This product has been customized for a customer in the United States who has given us permission to sell it worldwide.

Crafted from high-quality materials, the shell of the telephone is made of durable 304 stainless steel. However, we also offer options for the shell material, such as brass and zinc alloy. Our aim is to provide flexibility and cater to various customer preferences.

The push button switch on the telephone is designed to be customizable. We offer a range of options for the button header, including different patterns and symbols.

Speaking of the push button switch itself, it is a white switch with 1NO (Normally Open) self-recovery function. When you press the button to activate the power, it will automatically turn off once you release your hand.

Our product is compatible with various voltage options, including 3V, 5V, 12V, 24V, 110V, 220V, and 380V. The integrated LED lamp beads are dual-core and do not require distinguishing positive and negative poles. You can choose from a range of vibrant colors, such as red, yellow, blue, green, and white. However, please note that currently, we only produce monochrome products.

In terms of functionality, the telephone has an impressive waterproof rating of IP67, making it suitable for outdoor use. It can withstand exposure to water and moisture without compromising its performance.

The product is designed to handle a current of 3A at 250V, and it has a remarkable service life of up to 100,000 cycles. This ensures its longevity and reliable operation.

Lastly, the bottom of the telephone is specifically designed with an RJ9 plug, allowing for easy installation. The RJ9 connector enables seamless connectivity and compatibility with a wide range of telephone and headset devices.

With our feature-rich telephone, incorporating the versatile RJ9 connector, we aim to provide customers around the world with a high-quality, customizable, and durable communication solution.

How to Test RJ9 Connector Pushbutton Switch?

As we can see from the picture, the base of the product is different from that of conventional buttons, which is detected by the telephone wire.

The base has four holes, interface 1 and interface 4 are LED, interface 2 and interface 3 are switch pins. (as shown in the figure).

Step 1: Begin by turning on the DC switch power as depicted in the diagram. Adjust the current and voltage settings to the appropriate values, taking care not to set them too high. During the testing phase, ensure that the current does not exceed 0.5A to avoid garbled values.

Step 2: Proceed to connect the terminal to the designated interface shown in the diagram. Upon connection, the product’s built-in light should remain steady. Press the button to verify the lamp color, which should be normal. For instance, in the case of a white lamp bead, it should emit a steady white light. Any deviations from the expected colors, such as yellow or no illumination, indicate substandard products.

Step 3: Next, perform a thorough check of the product’s functionality. Verify that the lamp color corresponds to the designated voltage. Assess the button’s surface to ensure consistent tactile strength. Confirm the stability of the self-locking and self-recovery functions. Additionally, assess for any issues such as oil or cassette residue, noise, or delays.

Finally, examine the product’s appearance for completeness, absence of defects, deformation, stains, scratches, and other imperfections. Ensure that the RJ9 connector is properly integrated, facilitating seamless compatibility with telephone and headset devices.

By following these steps and incorporating the reliable RJ9 connector, we assure our customers of a comprehensive evaluation process to ensure the high quality and performance of our product.

How to Get rj9 Connector Push Button Switch Samples?

Thank you for your interest in FILN push button switches. We are delighted to offer you complimentary samples for testing purposes. You can reach out to us directly or leave a message below, and we will respond promptly.

As a specialized manufacturer of push button switches, FILN provides personalized solutions tailored to your specific needs. With our expertise, we can customize switch products to meet your requirements.

In addition to our commitment to providing high-quality push button switches, we also offer the flexibility of incorporating the RJ9 connector. This ensures seamless compatibility with telephone and headset devices, allowing for a versatile and integrated communication experience.

Please don’t hesitate to contact us or leave a message below to explore how FILN can assist you in obtaining the perfect push button switch with the added convenience of the RJ9 connector. We look forward to serving you and meeting your switch customization needs.

About FILN Push Button Switch

Filn is a renowned manufacturer specializing in the production of push button switches and signal lamps. Our products find extensive applications in various industries, including machinery, electric power, and automation.

With a focus on middle and high-end users, Filn has emerged as the preferred choice in China. Our state-of-the-art production equipment, testing instruments, and rigorous adherence to the ISO9001 quality assurance system ensure superior quality products.

Apart from the 19mm mounting hole size, Filn offers a comprehensive range of sizes, including 12mm, 16mm, 22mm, 25mm, 28mm, 30mm, and 40mm. We are also actively developing buttons in sizes of 8mm and 10mm to meet diverse customer requirements.

In terms of shell materials, we provide options such as stainless steel, brass with nickel plating, black-plated zinc aluminum alloy, as well as other options like red plating and gold plating.

Our push button switches boast an impressive mechanical life of 100,000 times, and they are designed with a premium silver dot inside. Additionally, they hold a waterproof rating of IP67. Our products have obtained certifications including UL, CE, and ROSH, reflecting our commitment to quality and safety standards.

Filn takes pride in offering highly competitive pricing for our white push button switches, which feature the most comprehensive range of types in the industry. We prioritize product quality and have received acclaim from customers both domestically and internationally. Our dedication to continuous improvement drives us to develop new push button switches, further enhancing our brand image.

Within our production workshop, we operate five production lines, and we have no minimum order quantity (MOQ) requirement. If you are interested in our products and require samples, please feel free to contact us directly at inquiry@cnylin.com.cn.

With our wide range of high-quality pushbutton switches, Filn is committed to meeting the diverse needs of customers while continuously strengthening our brand presence.

RJ9 Connector Switch Parameters
