6 Pins 120V 15A Red LED Momentary On Off On Rocker Switch

  • Mode: KCD4-0101-23
  • Voltage: 3V,  5V,  6V,  12V,  24V, 13V, 110V, 120V, 220V, 240V, 250V, 380V
  • Keyword:on off on rocker switch
  • Color: Red, White, Blue, Green, Yellow, Black
  • Material: Stainless Steel
  • Certification: CE CCC ROSH IP67 UL
  • Waterproof grade: IP67
  • Email: inquiry@cnylin.com.cn
  • Download PDF: 12V 15A Blue LED ON OFF ON Rocker Switch

What are the features of the 6pin on Off on Rocker Switch?

6pin on off on rocker switch has the function of on off on and with 3 gears, also has built-in light. In some DPDT circuits, it can be replaced with a 6 pins on off on rocker switch, it can save the cost, and is more convenient for use. Meanwhile, the LED light is normally on, also can be controlled by the switch circuit. The LED light will bright up when the product’s one side is pressed down.

6 pin 120v 15A RED LED momentary on off on rocker switch The open size of the product’s panel is 30*22mm. It has 3 gears of on off on, and the size of the connecting pin is 6.3*0.8mm, the pin’s material is nickel plating, which has better corrosion resistance, oxidation resistance.

6-pins-on-off-on-rocker-switch

2.6 pin 120v 15A RED LED momentary on off on rocker switch The cover of the product adopts high-temperature resistant PC material, the high-transparent light PC material not only ensures that the lights are more beautiful, but also more durable. The cover can achieve the colors of red, green, yellow, blue, white, black. Regularly, the pad printing on the cover is I O II, means the function of on off on, we can accept custom other pad printing.

3.6 pin 120v 15A RED LED momentary on off on rocker switch,We can produce the product with light or without light, the LED light has the colors of red, green, yellow, blue, white. Meanwhile, the LED can achieve a variety of voltages, such as 3V, 5V, 6V, 12V, 24V, 48V, 110V, 220V, 250V, 380V.

4.6 pin 120v 15A RED LED momentary on off on rocker switch.The current of the product is 15A 250VAC, the inner contact’s diameter is 3.5mm, and the thickness is 0.2mm. The drawboard and connection pin both adopt nickel-plated material.

5.6 pin 120v 15A RED LED momentary on off on rocker switch,The base of the product adopts PA66 enhanced material, the maximum temperature resistance can reach 260 degrees. It is also a flame-retardant material, and it is more safe in use.

6.6 pin 120v 15A RED LED momentary on off on rocker switch into the hole of 30*22mm in the mounting panel, this installation is simple and fast, the panel’s thickness is between 2-5 mm.

What is a on off on rocker switch ?

The 6 pin 120V 15A red LED momentary on off on rocker switch is often integrated in the control panel of the device. For example, in the united states, the input voltage of the device is 120V, when the switch is on the gear of I or II, the device will start to work and the light is on.

on-off-on-rocker-switch

How to wire a on off on rocker switch ?

Please see the wiring diagram below, this wiring method is the most conventional wiring method for 15A on off on rocker switch. When switch is on the position “O”, the device is not powered on, and the light is not on. When the switch is on the position “I” or “II”, device starts to work, and the light is on.

Momentary on off on rocker switc

What are the advantages of FILN’s 15A on Off on Rocker Switch?

1.There is no MOQ, you can purchase 15A on off on rocker switch from one piece.

2.The 15A on off on rocker switch had passed the certifications of CE, ROSH, it can be sold in the European region.

3.The product can achieve a variety of voltages according to customer’s requirement, such as 12V 15A on off on rocker switch, 230V 15A on off on rocker switch, etc.

4.Filn’s sales staffs have 15 years of overseas sales rocker switch experience, and master the foreign trade processes of various countries, they can provide the online services 7*24 hours.

5.Filn has a professional production team, 15A on off on rocker switch is fully automated production. We can deliver 10,000 pieces product to customers within 5 working days.

6.We can provide the overall complement scheme.

7.The quality guarantee period of 15A on off on rocker switch of Filn is 5 years, Filn will replace the problem product free of charge during the warranty period.

120V on off on rocker switch

How to buy a 6 pin on off on rocker switch ?

6 pin  15a on off on rocker switch ,50 pieces products are packed in one box, and 1000 pieces are packed in one carton. The weight of 50 pieces is 1.5KG. If you purchase 15A on off on rocker switch in a small quantity, you can place an order at www.cnfiln.com, we have sufficient inventory of the conventional products and can arrange the delivery as soon as receiving orders.

If you need to customize the product or need the supporting wiring harness, you can list your requirements, such as connect the wire in advance, or pre-install customized quick connection terminals, or need special voltage, you can email us, our email address is inquiry@cnylin.com.cn.

Filn has 20 years of experience in 6 pins 15A on off on rocker switch producing. It also has a professional rocker switch R&D team, they can provide the customized scheme for you within 24 hours. Filn’s sales staffs also have over 10 years of overseas sales experience, they can communicate and solve the international trade problems. If you have any questions about the rocker switch, please contact us, our email address is inquiry@cnylin.com.cn.

Product Item KCD-0101-23
Panel Mount Diameter 22*30mm
Contact Way With wire
Install Way Buckle
Lamp Type LED
Rated voltage 3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color Red,white,blue,green,black,yellow
Shell Material brass plated nickel
Base Material PA66 nylon
Terminal Material brass
Applications Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current 15A
