22mm 10A IP68 Blue Momentary 4 Pole Push Button Switch
- Mode: FLM22-FW-1
- Keyword: 4 Pole Push Button Switch
- Voltage: 220V (AC)
- Current: 10A
- Color: Red, Blue, Green, Yellow, White
- Material: Copper, Stainless Steel
- Certification: CE, CCC, ROSH, IP67, UL
- Waterproof Grade: IP68
- Wire Specification: AGW22
- Email: [email protected]
- Download PDF: 22mm 10A IP68 Blue Momentary 4 Pole Push Button Switch
4 pole push button switch parameters
|Production Series||FLM22-FW-1||Light Guide Button||PC plastic|
|Button Shape||round||Actuator||304 Stainless steel|
|Button LED Color||Red blue green yellow white||Housing Sleeve||H59 nickel plated brass/304Stainless steel|
|Mechanical Life||The 500 thousand time||Button Pin||H62 copper alloy|
|Electrical Life||The 100 thousand time||Rubber Ring||SIL silica gel|
|Protection Level||IP65 IK08||Nut||H59 nickel plated brass|
|Rated Voltage||220V(AC)||Housing||PA66+GF20% nylon|
|Rated Current||10A||Light Source||LED|
|Rated Power||2200W||Resistor||Metal film|
The description of the 22mm 10A IP68 blue 4 pole momentary push button switch
The biggest feature of the product is the bottom with glue and a direct lead line. This can achieve the overall waterproof and reduce costs. The following is the detailed description of the 4 pole push button switch.
- The mounting hole size of the product is 22mm, you just need to open the hole which size is between 22.2 mm to 22.5mm, then put the product into the install hole.
- The product has 4 lines. The color of the lamp line represents the color of the switch, and the other 2 lines are switch lines.
- The head of the product can achieve a variety of bush button shapes, such as flat head without lamp, high head without lamp, flat head with ring circle, flat head with power symbol, high head with ring lamp, high head with power symbol and so on.
- The product’s shell has a variety of materials.
- The product with stainless steel(has high corrosion resistance, usually used in the environment of salt fog and wet, which has high quality).
- The cost of the product with brass is low and economical.
- The product with zinc aluminum alloy is plated to black (in addition to black, we can produce silver, blue, yellow, green, red and many other colors).
- The product has a variety of colors, such as red, green, yellow, blue, white.
- The product can achieve a variety of voltage, such as 3V, 6V, 12V, 24V, 36V, 110V, 220V.
- The mechanical life of the product is 100,000 times, and its current are 3A, 5A etc.
- The waterproof rating of the product is IP68, the waterproof design of the bottom with glue allow the switch to achieve a better waterproof effect.
- The pressure tolerance standard of the product is 1800 V, which temperature resistance is between minus 40 degrees and 80 degrees.
- The 4 pole push button switch is a direct lead connection, we can connect different fast terminals according to customer’s demand, which is convenient for wiring.
How does the 22mm 4 pole push button switch work?
The product is divided into two types of momentary push button switch and push button switch with lock.
The product is installed on the mechanical equipment, in the case of electric circulation, press the push button switch, the machine starts. When release the push button, the machine is power off and stop working.
The product with lock is installed on the mechanical equipment, in the case of electric circulation, press the push button switch and release your hand, the machine is power on and starts. When press the push button again and release your hand, the machine is power off and stop working.
Other users also asked the following questions
The difference between two-color light line and pubic line of the product:
We have two types of public lines, one is the common anode line (positive pole) and the other is the common cathode line (negative pole).
The number of lamp volts of 4 pole push button switch:
The product has a variety of voltage, such as 3V, 6V, 12V, 24V, 36V, 110V, 220V, we will adjust our resistance value according to customer’s requirement.
How to connect the wire with the 12V red green 4 pole push button switch?
The switch line and lamp light of the product is independent, 2 switch lines NO control equipment, the lamp line, red and green line and the public line link with the module, through the module to control the color change of the lamp.
How to purchase the 4 pole momentary push button switch?
The product has a variety of applications of coffee machine, doorbell, controller, access control.
You can purchase the product at www.cnfiln.com, or you can via offline email communication to purchase the product.
Per weight of the product is about 0.05 kg, based on customer’s quantity to determine the delivery way. The quantity of one box is 200 pieces, and the quantity of one carton is 800 pieces.
The product has no MOQ requirement. We can provide the samples free of charge for your test.
If you are interested in our product or you need the samples, please contact us directly, our email address is [email protected]
