Filn 250V 15A Yellow LED 4 Prong Rocker Switch

The description of Filn 250V 15A LED 4 prong rocker switch.

The mounting hole size of the 15A rocker switch is 22*30mm, you need to open a hole of 22*30mm on the panel and install it. The thickness of the rocker switch panel should be between 0.8 to 4mm. Otherwise, the waterproof rocker switch will not be tight, resulting in poor use effect.

The 4 prong rocker switch has 6 colors of red, green, yellow, blue, white. It can be produced rocker switch with lamp, the black 4 prong rocker switch is without lamp.

The 4 prong rocker switch’s waterproof rating is IP44 and it is not waterproof.

The maximum current of the 4 prong rocker switch can up to 16A 250V.

The UL 4 prong rocker switch can achieve a variety of voltages, such as 3V, 6V, 12V ,24V, 110V, 120V, 220V ,250V ,380V, etc. 110V and 120V 15A rocker switch are usually used in European market, while 220V and 250V are usually used in China market.

Filn 250V 15A Yellow LED 4 Prong Rocker Switch

The KCD4 4pins rocker switch is double circuit and has the functions of on off and self-reset on off.

The base of the 12V15A rocker switch adopts nylon double material, its temperature resistance can reach 260 degrees, ensuring that the rocker switch contact with the heat plastic does not melt at a high current.

The 4 prong rocker switch adopts flame-retardant and high temperature resistant material. Its plug adopts copper material in order to strengthen the conductivity, it can be used with the cold pressure terminal wiring of 6.3mm.

The cover is light insulated, attached indicator, and the indicator lamp comes with a resistance, don’t need to additional wiring.

Spring device, lubrication device, have a swift response. Press smoothly, and the switch sound clear.

Double-roll alloy connector, increase composite silver points, enlarge the contact surface and strengthen the load capacity.

How to wire a 4 prong rocker switch?

Regarding the wiring diagram of the 4 pins 2 gears lighted illuminated 30A rocker switch is as follows.

Where does the LED 4 prong rocker switch used?

The 4 prong rocker switch has a variety of applications, such as dispenser, treadmill, computer audio, battery car, motorcycle, massage, toy car, etc and other small high-capacity power switches for home appliances, office equipment, and kitchen equipment, etc.

If you use a high power product, please choose prong rocker switch with 30A red copper pin. Such as arc welder. heating apparatus, electric cake pan, electric baking oven, electric oven,etc.

Filn 250V 15A Yellow LED 4 Prong Rocker SwitchFiln 250V 15A Yellow LED 4 Prong Rocker Switch

How to buy a yellow 4 prong rocker switch ?

The yellow 4 prong rocker switch has a variety of voltages, such as 12V rocker light switch, 110V 4 prong rocker switch, etc, you can email us. Please list the information of voltage, panel size, current, service condition, we can recommend the appropriate rocker switch for you, our email address is inquiry@cnylin.com.

If you need the conventional rocker switch, such as KCD4 rocker switch, KCD1 waterproof rocker switch, you can place an order at www.cnfiln.com, we will arrange the delivery within 24 hours.

The advantages of LED rocker switch.

1.Filn LED rocker switch has no MOQ requirement, you can purchase from one piece. In addition, the custom rocker switch has no MOQ.

2.Filn can provide custom services, If you want the rocker switch with wire directly, we can weld the wire directly on the rocker switch.

3.The 4 prong rocker switch had passed the certifications of UL, CE, ROSH, etc. All the 4 prong rocker switch are produced according to ISO90001 quality management system standards, ensuring the product’s quality and stability.

KCD3 2 prong rocker switch

4.Filn has a professional team of engineers for R&D and design rocker switch, and a team of engineers for rocker switch mould. They can complete new rocker light switch design and mould within 30 to 40 days.

Filn’s sales staff are all sales engineers who can solve and respond to any customer questions regarding the rocker switch in a timely manner.

Filn has over 20 years of experience in 4 prong rocker switch producing, also has a professional rocker switch R&D team, they can customize appropriate plan for you within 24 hours. Filn has over 10 years of overseas sales experience, they can timely communicate and solve international trade problems. If you have any questions about rocker switch, please contact us immediately, our email address is inquiry@cnylin.com.cn.

250V 4 prong rocker switch-2
LED 4 prong rocker switch
Yellow 4 prong rocker switch
Product Item KCD4-0101-21
Panel Mount Diameter 22*30mm
Contact Way With wire
Install Way Buckle
Lamp Type LED
Rated voltage 3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color Red,white,blue,green,black,yellow
Shell Material brass plated nickel
Base Material PA66 nylon
Terminal Material brass
Applications Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current 15A
