In a push button switch, the on off button symbol typically represent the different states or functions of the switch. Here are the common symbols and their meanings:

1. “I” or “1”: This symbol represents the “on” position or state of the switch. When the switch is in this position, the circuit is closed, and the device or system connected to the switch is powered on.
2. “O” or “0”: This symbol represents the “off” position or state of the switch. When the switch is in this position, the circuit is open, and the device or system connected to the switch is powered off.

These symbols are often accompanied by the corresponding words “On” and “Off” for clarity. The symbols allow users to easily identify the switch’s current state and control the power flow to a device or system.

Product Parameters:

A short story about this push button switch

Related products:

At the beginning of 2019, many American companies resumed work. Due to the high cost of customized services and the hourly wage of production workers reaching 18 US dollars, an American company that specializes in vending machines contacted our company for assistance.

The vending machines were mainly used in amusement parks, with most of the usage time at night. Therefore, they needed a 30mm 2-step push button switch with a long lifespan and comfortable light brightness.

After discussing the customer’s usage scenario and requirements with our button engineering team, they spent a week adjusting the LED brightness according to different LED beads and resistance values.

The American customer was very pleased with the results. They chose two fresh colors, emerald green and sky blue. The button engineer then spent three weeks improving the metal push button switch’s lifespan to 800,000 times and conducted tests. Since then, the customer has been working with FILN until now.

Differences in power on switch symbol:

On off switch symbols are commonly seen on rocker switches or toggle switches with I/O symbols, but they are also present on the surface of push button switches. These symbols can be a power symbol, a company logo, or any other symbol desired by the customer. As a push button switch manufacturer, we offer customizable options for on off switch symbols to meet the specific needs of our customers.

Our push button switches are available in various sizes, styles, and colors, and can be designed with different on off switch symbols to match the branding or functionality of the device. With our advanced production technology and experienced engineers, we can provide high-quality push button switches with reliable on off switch symbols that meet the most demanding applications.

Whether you need a push button switch with a simple power symbol or a customized on off switch symbol, we can provide the perfect solution for your application. Contact us today to discuss your requirements and get a quote for your project.

Features of on off switch symbol:

Note: This table is not comprehensive and the advantages and disadvantages may vary depending on the specific context and application of the on off switch symbol.

The principle of 2 step push button switch：

The 2 step push button switch is a type of switch that utilizes a button to push the transmission mechanism, causing the moving contact and the static contact to connect or disconnect, thus switching the circuit. On the surface of the push button switch, there may be an on off switch symbol, which can be a power symbol, a logo, or any other symbol that the customer requests.

The working principle of the 2 step push button switch involves an electromagnet adsorption device that generates a magnet instead of electricity when the button is pressed, allowing the circuit to be connected or disconnected, thus achieving remote control of the line and other functions.

This switch comes in both self-locking and non-locking variants, with the self-locking variant having a locking function that keeps the switch in the on position until it is manually turned off.

The 2 step push button switch is also waterproof, with a default waterproof rating of IP65. While its surface is waterproof, the degree of waterproofness during use may be affected by various factors such as installation method, installation direction, airflow, pressure difference, gas rebound, and working voltage.

However, if the customer requires a higher waterproof rating, FILN company can provide a customized IP67 rating and installation method.

In summary, the 2 step push button switch with its on off switch symbol is a reliable and efficient switch that can be customized according to the customer’s requirements, with both self-locking and non-locking variants available, and a waterproof rating of up to IP67.

Note: Click to buy video products directly 19MM push button switch, 30MM symbol button please contact us.
