Red LED IP67 3 Pin Rocker switch KCD1-102N

  • Mode: FL3-KCD1-0111 (KCD1-102N)
  • Voltage:3V, 5V, 6V, 12V, 24V,13V, 110V, 120V, 220V, 240V, 250V, 380V
  • Keyword: 3 Pin Rocker Switch
  • Color: Red, White, Blue, Green, Yellow, Black
  • Material: PC
  • Certification: CE CCC RoSH IP67 UL
  • Waterproof grade: IP67
  • Email: [email protected]
  • Download PDF: Red LED IP67 3 pins rocker switch KCD1-102N

3 pin rocker switch parameters

Product Item FL3-KCD1-0111
Panel Mount Diameter 19.5*13mm
Contact Way solder pin
Install Way Buckle
Lamp Type LED
Rated voltage 3v, 5v, 6v, 12v, 24v,13v, 110v, 120v, 220v, 240v, 250v, 380v
Lamp Color Red,white,blue,green,black,yellow
Shell Material brass plated nickel
Base Material PA66 nylon
Terminal Material brass
Applications Coffee machine, kitchen equipment, household appliances, automobiles, medical equipment, industrial equipment etc
Current 5A

The description of the red LED IP67 3 pin rocker switch KCD1-102N.

  • The mounting hole size of the 3 pin rocker switch is 19.5*13.5, so you just need to open the hole size of 20*15 on the rocker switch panel. The panel thickness of the rocker switch should be over 0.8mm so that the rocker switch and panel installation will be very firm.
  • The KCD1-102N 3 pin rocker switch can achieve a variety of colors, such as red, green, yellow, blue, white, black, etc. Among these, red, green, yellow, blue and white can achieve the rocker switch with lights. The black rocker switch is not with light.
  • The 3 pin LED rocker switch is waterproof, and the waterproof rating is IP67, it can be used outdoors.
Red LED IP67 3 Pin Rocker switch KCD1-102N
  • The current of the red 3 pin rocker switch is 5A 250V, which can be used on the device of which power is 1000W.
  • The temperature resistance of the product is 125 degrees, and the service life is 100,000 times. The base of the rocker switch can be achieved in white and other colors.
  • The 3 pin LED rocker switch has 3 pin, the yellow is the light pin, and the middle one is the public pin, the side one is the power pin, both the public pin and the power pin are white.
  • The pin size of the red rocker switch is 4.8mm, you can buy the 4.8mm plug-in spring.
3 pin rocker switch

How to wire a 3 pin rocker switch?

The wiring way 1

the light of the rocker switch controls the device.

The indicator lamps in the device don’t need to distinguish the positive and negative pole, connect the positive pole of the switch to the power, connect the negative pole of the switch to the indicator light, then connect the other pole of the indicator lamp to the negative pole of the power. This makes the rocker switch control the equipment’s on and off.

The wiring way 2

the rocker switch controls the switch’s LED light and device.

The general process of wiring is the same, just connect the power directly to the yellow pin of the switch, the other positions and wiring ways are the same as the wiring way 1. This makes the rocker switch control the LED lamp of the switch and the device’s switch.

The 3 pin rocker switch has three wiring pins, the yellow is the lamp pin of the rocker switch, the remaining two are the switch pin of the power.

How to buy a 3 pin rocker switch?

Technical-team

If your purchase quantity is small or your time is urgent, you can place an order at www.cnfiln.com, we will arrange the delivery on the same day.

If you need to customize the special rocker switch, you can email us, we will give you a satisfactory solution within 24 hours.

rocker switch

Except for the KCD1 3 pin rocker switch, Filn also produces other types of rocker switches, such as KCD2, KCD3, KCD4.

More rocker switch types can be viewed here.

The rocker switch of Filn had passed the certifications of UL, CE, TUV, IP67. We produce the products in strict accordance with the certification standards of the ISO90001 quality management system.

Filn also has professional rocker switch test equipment, which can ensure the product passes the waterproof test, pressure resistance test, current test, aging test and so on.

Except for the rocker switch, Filn also produces supporting indicator lights, push-button switches, temperature control switches and so on.

If you want to customize any switches, please contact us immediately, our email address is [email protected].
