110V Momentary 6 Pin Push Button Switch Double Color button
- Mode: FLM22-11FJZ
- Voltage: 36V(DC) 250V(AC)
- Current: 1A(DC) 0.5A(AC)
- Color: Red, Blue, Green, Yellow, White
- Material: Copper, Stainless Steel
- Certification: CE, CCC, RoSH, IP67
- Waterproof grade: IP67
- Email: firstname.lastname@example.org
- Download PDF: 22MM 8 Pins Red LED 110V Momentary Push Button Switch
A 110V Momentary Push Button Switch is a standard button switch designed to operate at a voltage of 110 volts.
It belongs to a specific voltage range and is suitable for specific applications. The term “momentary” describes its functionality, meaning that when the switch is pressed, the circuit is closed, enabling the device to function. Releasing the button causes it to automatically return to its original position, thereby opening the circuit.
Introduction to the 6-Pin Push Button Switch
Diving into the world of electronics, the 6-pin push button switch stands out as a versatile and indispensable component. Central to myriad electronic applications, this switch, synonymous with the Push Button Switch 6 Pin, is known for its robust design, DPDT functionality, and adaptability in various conditions. Whether you’re exploring its waterproof variants, understanding its micro tactile design, or simply seeking its applications, this guide illuminates every facet of the 6-pin push button switch. Read on to unravel its features, advantages, and tips to choose the right one for your needs.
When it comes to electrical components, switches play an instrumental role in enabling or disabling electrical circuits. One such switch, known for its versatility and application across a wide range of electronics, is the 6-pin push button switch.
Synonyms and Latent Semantic Indexing Keywords
- Push Button Switch 6 Pin
- 6-pin push-button on/off switches
- Push Button Switch, DPDT 6 Pin 1 Position Self-Locking
- 7x7mm / 8x8mm Micro Tactile Push Button Switch 6 Pin
- 6 Pin Push Switch Working
- 22mm Stainless Steel Push Button 6-Pin ON/OFF
- 6 Pin DPDT Mini Push Button (on-on)
- 6 Pin Push Button Switch DPDT 0.1A 30VDC
Features and Use-cases of the 6-Pin Push Button Switch
- Design and Composition: Often, a 6-pin push-button switch comes with a DPDT (Double Pole, Double Throw) design. This means it has two input contacts and can switch between two different outputs based on the button’s position. The Push Button Switch 6 Pin 1 Position Self-Locking is an exemplary model of this kind of switch.
- Micro Tactile Variant: The 7x7mm / 8x8mm Micro Tactile Push Button Switch 6 Pin is perfect for applications that require a compact size with the same DPDT functionality. Ideal for use in tight spaces or on PCBs (printed circuit boards).
- Durability and Robustness: Many 6-pin push-button switches are made of stainless steel, like the 22mm Stainless Steel Push Button 6-Pin ON/OFF, ensuring durability and resistance to external environmental factors.
- Applications: Due to its design and functionality, 6-pin push-button switches find their use in various electronic applications. From simple home electronics to industrial machines, you can find them in places where switching between two operations is essential.
- Working Principle: The 6 Pin Push Switch Working mechanism is quite straightforward. When pressed, the switch establishes a connection between its two sets of contacts, enabling or disabling a circuit.
- Variants and Sizes: The 6-pin push button is not limited to one size or form factor. From miniature models like the 6 Pin DPDT Mini Push Button to larger, more robust versions, there is a fit for every need.
- Voltage and Current Specifications: One common specification you might come across is the “6 Pin Push Button Switch DPDT 0.1A 30VDC”. This indicates that the switch can handle a maximum current of 0.1A at a voltage of 30VDC.
- Waterproof Variants: For applications that may be exposed to moisture or water, waterproof 6-pin push-button switches are available, ensuring functionality is maintained even in damp conditions.
- On-On Vs. Momentary: Depending on the need, you can find switches that stay in the ‘on’ position until toggled again (on-on) or those that only remain ‘on’ as long as they’re pressed (momentary), like the ones available at Indicator Light.
- Indicator Lights and Symbols: Some 6-pin push buttons come with power symbols or built-in indicator lights to show the status of the switch.
- Where to Buy: For a wide selection of 6-pin push button switches and other related products, visit Indicator Light’s catalog.
6-pin push button switches are versatile and essential components in the world of electronics. Whether you’re designing a new electronic device or repairing an old one, understanding the functionalities and varieties of these switches can make your task easier. For more information on push button switches and other related products, Indicator Light is a recommended resource.
Additional Insights on the 6-Pin Push Button Switch
Advantages of Using 6-Pin Push Button Switches:
- Flexibility in Circuit Design: With the ability to toggle between two operations, designers have greater flexibility in integrating multiple functionalities into a single device.
- Long Lifespan: Quality 6-pin push button switches, especially those made with durable materials like stainless steel, can withstand countless presses without wear or failure.
- Safety: Many 6-pin push-button switches come with a self-locking mechanism. This ensures that unintended activations are minimized, especially in critical applications.
- Compact Design: Despite their multiple pins and dual-functionality, many of these switches, especially the micro tactile variants, are compact, making them suitable for devices where space is a premium.
- Ease of Installation: With clear pin markings and standardized designs, installing or replacing these switches is typically straightforward.
Tips for Choosing the Right 6-Pin Push Button Switch:
- Determine the Use-case: Understand the primary function of the switch. Do you need a momentary action or a maintained (on-on) action? For instance, for a car ignition, a momentary car push button ignition switch would be ideal.
- Check the Ratings: Always check the voltage and current ratings of the switch to ensure it matches the specifications of your circuit or device.
- Environment Factors: If the switch is going to be used in an environment exposed to moisture, dust, or other external factors, considering a waterproof push-button switch would be a wise choice.
- Additional Features: Some switches come with added features like LED indicators, power symbols, or even custom engravings. Decide if these features add value to your application.
- Supplier Reliability: Ensure that you purchase from a reliable supplier. Companies like Indicator Light offer a wide range of switches and provide detailed specifications for each product, making the selection process easier.
In the vast realm of electronic components, the 6-pin push button switch holds its unique position, offering dual-functionality in a simple design. Whether you’re an electronics hobbyist, a professional designer, or someone just curious about switches, the depth and breadth of applications for these switches is truly impressive. As always, ensure you select the right switch for your application, keeping in mind the device’s requirements and the environment it’ll be used in.
How Much Does a 6 Pin Push Button Switch Cost?
When it comes to purchasing a 6 pin push button switch, understanding the price range is crucial for making informed decisions. In this article, we will explore the prices offered by different suppliers and provide recommendations based on your needs. So let’s dive in!
Suppliers and Prices
The price and availability of 6 pin push button switches can vary depending on the supplier. Here’s a breakdown of the prices offered by different platforms:
- Price Range: $7.67 to $20+
- Note: Prices depend on the model and features of the switch.
AliExpress offers a wide range of 6 pin push button switches with prices ranging from $7.67 to over $20. The specific price can often depend on the model and its distinct features.
- Price: $0.03 per piece
- Note: For orders of 10,000 or more
Global Sources provides a fantastic deal with a price of just $0.03 per piece for a 6-pin connection mini push button switch with a lock feature. However, this price is specifically for bulk orders of 10,000 or more.
- Price Range: $0.01 to $100
- Note: Depending on specific parameters and features
Made-in-China offers a vast price range for 6 pin push button switches. Prices can start as low as $0.01 and go up to $100. The price largely depends on the specific parameters and features of the switch in question.
- Price: Varies
- Note: Specific pricing not available in search
Amazon provides a variety of 6 pin push button switches, but unfortunately, the search didn’t provide specific pricing details. It’s best to check directly on the Amazon platform for the most accurate and up-to-date pricing information.
- Price Range: $10 to $150
- Note: Average price for switches, variety with 6 pins available
Home Depot offers a range of 6 pin push button switches with prices falling between $10 to $150. They provide a variety of models featuring 6 pins, giving you options to choose from.
Note: It’s important to remember that these prices are approximate values and can fluctuate based on the retailer, location, or even the supplier. For the most accurate and current pricing information, it’s always recommended to consult directly with the supplier or the specific online marketplace.
Based on the price ranges offered by different suppliers, here are some recommendations:
- For bulk purchases of 10,000 or more, Global Sources offers a competitive price of $0.03 per piece.
- If you’re looking for individual or smaller quantities, platforms like AliExpress or Home Depot may provide better options within their respective price ranges.
When purchasing a 6 pin push button switch or any other product, thorough research and comparison of different suppliers can ensure not only a good price but also quality and reliability. Keep in mind the price ranges provided by AliExpress, Global Sources, Made-in-China, Amazon, and Home Depot, and choose the supplier that best fits your needs.
Remember, prices can vary, so always double-check with the supplier or online marketplace for the most accurate and up-to-date pricing information. Happy shopping!
|$7.67 to $20+
|Prices depend on model and features
|$0.03 per piece
|For orders of 10,000 or more
|$0.01 to $100
|Depending on specific parameters and features
|Specific pricing not available in search
|$10 to $150
|Average price for switches, variety with 6 pins available
Application Scenarios for 110V Push Button Switch:
Taking the United States as an example, 110V push button switches are widely used in a variety of devices and applications.
The following are some common use scenarios and devices:
Home and commercial lighting systems: 110V pushbutton switches are commonly used to control indoor and outdoor lighting systems, including lamps, ceiling fans and other lighting fixtures. However, the function is rather limited and can only play on and light, not more functions.
Household appliances: 110V pushbutton switches are also often used in household appliances such as TVs, stereos, air conditioners, ovens, washing machines, etc. FILN offers high quality metal pushbutton switches that look more high-end and aesthetically pleasing when installed on equipment.
Power tools: Many power tools, such as drills, chainsaws, and electric lawn mowers, often use 110V pushbutton switches for start and stop control. The size of these pushbutton switches are relatively mini, FILN provides 8-40MM switches to meet more equipment use.
Mechanical equipment and industrial control systems: In mechanical equipment and industrial control systems, 110V pushbutton switches are commonly used to start, stop and control machine operation. This is where FILN switches are most used. Lighted pushbutton switches can effectively distinguish between various functions and energized conditions, and the color of the LED lights can visually respond.
Automatic doors and access control systems: Automatic doors and access control systems usually use 110V pushbutton switches as switching devices. FILN believes that traditional pushbuttons are the most durable in access control systems, which only need to be pressed to open or close the door, while nowadays there are accidents with swipe cards or automatic face swipes.
Security Alarm Systems: In home and commercial security alarm systems, 110V pushbutton switches can be used to trigger an alarm or emergency notification. When a special situation occurs, pressing the button in time can effectively alert the police and protect property.
These are just some common application scenarios and devices, in fact, FILN 110V push button switches are widely used in many other areas and devices.
Application of Momentary Push Button Switch:
The above describes in detail the various applications of the 110V push button switch in life.
However, some of them use the latching push button switch, while the application of momentary push button switch is indispensable.
The operation of this type of push button switch requires an operator to be present, like the button on a self-service beverage dispenser, where the momentary push button switch is selected because you want a beverage you need to press and hold the switch and release the button when the cup is close to being filled.
There is also a supermarket bread cutting machine, when you put a piece of bread in, close the glass door, just press the momentary switch, the machine will start to work normally, the process you only need to press this switch, it will automatically run the built-in timer, no need to keep pressing the momentary switch, saving us unnecessary operations! .
There are many other devices similar to this one. In short, the momentary push button switch is used in all walks of life for ease of operation.
22mm 110V Momentary Pushbutton Switch Introduction
The 110V momentary pushbutton switch is a thread-mounted, fixed type with a 22mm bore.
It is a versatile switch that can be configured to operate at a variety of voltages, and FILN switch factories can produce 2V, 12V, 24V, 110V, 120V, 220V, 277V and 380V.
This 110V pushbutton switch has 5 pins and features a normally open (NO) and a normally closed (NC) contact configuration. For the 8-pin version, it offers a 2 normally open and 2 normally closed contact configuration.
The pushbutton switch is designed in the shape of a metal cylinder featuring the power symbol, a circular illuminated ring. filn can change the power symbol based on a custom symbol you provide, similar to those found on car dashboards, which can have a unique effect.
The switch’s metal housing is available in three types: zinc alloy, stainless steel, and copper. The stainless steel option offers corrosion resistance and can withstand harsh environments such as coastal areas, kitchen equipment and outdoor applications. Custom 316 stainless steel is also available for greater corrosion resistance and longer service life.
The metal housing of the 110V momentary pushbutton switch is chrome plated, giving it an attractive appearance. When the LED light is illuminated, the recessed shape of the metal housing reflects the light, creating a visually stunning effect. This product is commonly used in household appliances such as wine coolers, freezers and ice machines.
An advantage of the 110V momentary pushbutton switch is that the metal housing can be produced in a variety of colors, such as red, green and black. After electroplating, the entire button has a colored appearance, providing a personalized touch that caters to different usage scenarios. Two- and three-color options are also available.
Overall, the 110V momentary pushbutton switch combines functionality, aesthetics and versatility, making it suitable for a wide range of applications in both residential and commercial environments.
How to Wire the 110v Momentary Push Button Switch?
There are four common wiring methods.
1. This is the most common connection, bridge connect a lamp pin and the switch’s NO pin, then connect them to the working device.
The public pin is connected to the positive pole of the power, the negative pole is connected to the device’s load, the other LED’s lamp pin is connected to the negative pole of the power.
When we press down the switch, the LED light inside the metal push-button switch is on and the device starts to work. On the contrary, release your hand, the device stops working and the light is off.
2. In this connection way, the built-in LED light is always powered up, so whether the switch is pressed or not, the light is always on.
When the switch is pressed, the device starts to work.
3. This connection way is exactly against the first way, the bridge connects the lights and NC pin with a heel jumper.
When the metal push-button switch is not pressed, the light is on and the device is always working.
When the switch is pressed, the circuit of the device starts to break off and stop work, the light is also disconnected from the power and is off.
4. In this connection way, the LED light is always powered up, but the switch is connected to the normally closed pin.
When the metal push-button switch is not pressed, the device is always working.
When the push-button switch is pressed, the circuit contact is disconnected and the device stops working.
Get Free 110v Momentary Pushbutton Switch
If you require small batch samples of the 110V Momentary Push Button Switch for testing or personal use, you can conveniently purchase them from our Speedway. We offer a selection of these switches to meet your specific needs.
Alternatively, you have the option to purchase directly from our official retail store located at www.cnfiln.com. Our online store provides a seamless shopping experience and offers a wide range of products, including the 110V Momentary Push Button Switch.
Moreover, our products are also available on our Amazon store. We are continuously updating the store with links to custom symbols, allowing you to choose the desired design for your specific application.
If you are an engineer and require samples for testing purposes, we recommend reaching out to our international trade department via email. They will assist you in obtaining the necessary samples and provide further information on pricing and specifications. You can contact them directly at email@example.com.
With over 10 years of experience in overseas sales, we are committed to delivering high-quality products and exceptional service. Our dedicated team is available 24/7 to assist you with any inquiries or requirements you may have.
110v Momentary Push Button Switch Parameters
|Light Guide Button
